Bently Nevada 330106-05-30-05-02-CN 3300 XL 8 mm Reverse Mount Proximity Probe

Bently Nevada 330106-05-30-05-02-CN 3300 XL 8 mm Reverse Mount Proximity Probe

Description

The Bently Nevada 330106-05-30-05-02-CN is a high-performance 3300 XL 8 mm reverse mount proximity probe designed for precise vibration and position monitoring in industrial rotating machinery. As part of the...

23 la gente está viendo esto ahora mismo

Disponibilidad: Bajas existencias: quedan 7

SKU: 330106-05-30-05-02-CN
Proveedora: Bently Nevada
tipo: Proximity Probe
Related Series:

Envíos y devoluciones

Entrega confiable a nivel mundial

  • Transportistas: Envíos a través de DHL, FedEx, UPS o USPS .
  • Envío: Los pedidos se procesan en 1-2 días hábiles y se envían dentro de 3-5 días hábiles .
  • Seguimiento: Detalles completos de seguimiento proporcionados por correo electrónico después del envío.

Garantía de devolución de dinero de 30 días

  • Garantía: período de devolución de 30 días para productos en stock y sellados de fábrica.
  • Condición: Los artículos deben estar sin abrir, sin usar y en su embalaje original.
  • Autenticidad: Garantizamos hardware 100% original y auténtico.

¿Necesitas más información? Consulta nuestra Política de envíos y reembolsos completa.

Autenticidad y garantía

  • Garantía genuina: Suministramos únicamente piezas de automatización industrial 100% originales, nuevas y selladas de fábrica .
  • Cobertura total: cada componente está respaldado por una garantía integral de 12 meses a partir de la fecha de compra.
  • Trazabilidad: Todos los productos se entregan con documentación original de fábrica y accesorios para un pleno cumplimiento industrial.

Soporte técnico y abastecimiento

  • Asistencia de expertos: Nuestro equipo técnico ofrece consulta gratuita para ayudarle a verificar la compatibilidad de los sistemas DCS y PLC.
  • Abastecimiento de piezas raras: nos especializamos en componentes obsoletos y difíciles de encontrar de Allen-Bradley, Siemens, ABB, HIMA y más.
  • Consultas al por mayor: contáctenos en pambo@5gplc.com para obtener precios por volumen o cotizaciones de proyectos personalizados.
Ver todos los detalles

Description

The Bently Nevada 330106-05-30-05-02-CN is a high-performance 3300 XL 8 mm reverse mount proximity probe designed for precise vibration and position monitoring in industrial rotating machinery. As part of the 3300 XL series, this probe is engineered to work seamlessly with the Bently Nevada Proximitor sensor system, providing reliable gap, amplitude, and position data for critical assets such as turbines, compressors, and pumps.

Features

  • Reverse mount configuration for installation in space-constrained environments.
  • M10 x 1 thread design for secure mounting.
  • Fully interchangeable with 3300 XL 8 mm and 5 mm system components.
  • Equipped with a miniature ClickLoc coaxial connector for reliable signal transmission.
  • Includes hazardous area agency approvals (CN/NEPSI).

Applications

  • Oil and Gas: Monitoring pumps, compressors, and turbines in refineries and extraction facilities.
  • Power Generation: Integrated into 3500 series protection systems for large-scale turbine monitoring.
  • Petrochemical: Precision monitoring of high-speed rotating equipment.
  • Heavy Manufacturing: Used in rolling mills and smelters to monitor shaft vibration and position.

Technical Specifications

Model 330106-05-30-05-02-CN
Probe Type 3300 XL 8 mm Reverse Mount
Thread Size M10 x 1
Total Length 0.5 meter (1.6 feet)
Connector Type Miniature ClickLoc coaxial
Agency Approvals CN (NEPSI)
Output Resistance 50 Ohm
Cable Capacitance 69.9 pF/m (21.3 pF/ft) typical
Weight 0.05 kg

Installation Guidelines

  • Ensure the probe is installed in a location free from excessive mechanical stress on the cable.
  • Use caution when handling the probe tip to prevent damage to the sensing element.
  • Ensure the connector is clean and free of debris before mating with the extension cable.
  • Maintain the minimum permissible cable bend radius to avoid signal degradation or cable damage.
  • Always power down the associated Proximitor sensor before connecting or disconnecting the probe.
  • Ensure proper grounding of the monitoring system to prevent EMI interference.

FAQ

What is the primary function of this probe?

This probe measures the distance between the probe tip and the observed target (e.g., a machine shaft), providing essential data for vibration and position analysis in the 3300 XL monitoring system.

What does the CN suffix indicate?

The CN suffix signifies that this specific unit is certified for use in hazardous areas according to Chinese (NEPSI) standards.

Is this probe compatible with older 3300 systems?

Yes, 3300 XL 8 mm components are electrically and physically interchangeable with non-XL 3300 5 mm and 8 mm components, provided the mounting requirements are met.
