Bently Nevada 135489-01 I/O Module with Internal Barriers

Bently Nevada 135489-01 I/O Module with Internal Barriers

Description

The Bently Nevada 135489-01 is an I/O module designed for the 3500 series machinery protection system. This specific module features internal barriers, providing intrinsically safe signal conditioning for four...

27 la gente está viendo esto ahora mismo

Disponibilidad: En existencias

SKU: 135489-01
Proveedora: Bently Nevada
tipo: I/O Module
Related Series:

Envíos y devoluciones

Entrega confiable a nivel mundial

  • Transportistas: Envíos a través de DHL, FedEx, UPS o USPS .
  • Envío: Los pedidos se procesan en 1-2 días hábiles y se envían dentro de 3-5 días hábiles .
  • Seguimiento: Detalles completos de seguimiento proporcionados por correo electrónico después del envío.

Garantía de devolución de dinero de 30 días

  • Garantía: período de devolución de 30 días para productos en stock y sellados de fábrica.
  • Condición: Los artículos deben estar sin abrir, sin usar y en su embalaje original.
  • Autenticidad: Garantizamos hardware 100% original y auténtico.

¿Necesitas más información? Consulta nuestra Política de envíos y reembolsos completa.

Autenticidad y garantía

  • Garantía genuina: Suministramos únicamente piezas de automatización industrial 100% originales, nuevas y selladas de fábrica .
  • Cobertura total: cada componente está respaldado por una garantía integral de 12 meses a partir de la fecha de compra.
  • Trazabilidad: Todos los productos se entregan con documentación original de fábrica y accesorios para un pleno cumplimiento industrial.

Soporte técnico y abastecimiento

  • Asistencia de expertos: Nuestro equipo técnico ofrece consulta gratuita para ayudarle a verificar la compatibilidad de los sistemas DCS y PLC.
  • Abastecimiento de piezas raras: nos especializamos en componentes obsoletos y difíciles de encontrar de Allen-Bradley, Siemens, ABB, HIMA y más.
  • Consultas al por mayor: contáctenos en pambo@5gplc.com para obtener precios por volumen o cotizaciones de proyectos personalizados.
Ver todos los detalles

Description

The Bently Nevada 135489-01 is an I/O module designed for the 3500 series machinery protection system. This specific module features internal barriers, providing intrinsically safe signal conditioning for four channels of Proximitor or seismic (accelerometer) transducers. It is engineered to interface directly with the 3500/42M Proximitor/Seismic monitor, facilitating the continuous monitoring of vibration and position parameters in critical rotating and reciprocating machinery.

Features

  • 4-channel input capacity for proximity and seismic vibration transducers.
  • Integrated internal barriers for hazardous area applications.
  • Internal terminations for simplified field wiring.
  • 16-bit ADC resolution for high-precision signal conditioning.
  • Compatible with Proximitor sensors and accelerometers.

Applications

  • Reciprocating Compressors: Monitoring crankcase and crosshead vibration for early failure detection.
  • Turbine Monitoring: Bearing and stator winding vibration analysis.
  • Oil and Gas: Gas compression and pipeline station reliability.
  • Chemical/Petrochemical: Monitoring of critical rotating equipment in hazardous environments.

Technical Specifications

Parameter Specification
Sensor Supply -24 Vdc @ 4 mA
Proximitor Input 0-10 Vdc
Accelerometer Input +/- 5 V or +/- 10 V
Frequency Range 0.09 Hz to 30 kHz
Resolution 16-bit ADC
Operating Temperature -40 degC to +70 degC
Storage Temperature -40 degC to +85 degC
Humidity 5% to 95% RH (non-condensing)

Installation Guidelines

  • Slot Positioning: The 135489-01 must be installed in the rear of the 3500 rack, directly behind its corresponding 3500/42M main module.
  • Rack Depth: Internal Barrier I/O modules are deeper than standard modules; ensure your cabinet has at least 50mm (2 in) of additional clearance.
  • Wiring Separation: Maintain a minimum 50mm separation between safe area wiring and hazardous area field wiring. It is recommended to route hazardous field wiring above the rack and safe wiring below.
  • Handling: Ensure proper ESD precautions are taken when handling the module. Always power down the rack before inserting or removing any module.

FAQ

What is the 135489-01?

It is a Bently Nevada 3500 series I/O module equipped with internal barriers, designed to provide intrinsically safe signal conditioning for up to 4 channels of vibration or proximity sensors.

What is the primary function of this module?

The module conditions input signals from transducers, converts them into digital values, and compares these values against user-programmed alert and danger setpoints to protect critical machinery.
