Description

The Emerson DeltaV KJ3002X1-BA1 (12P0680X122) is a high-reliability power supply module designed for the DeltaV S-series control system. This module provides essential power conversion and distribution to the system backplane, ensuring stable operation for I/O cards and controllers in demanding industrial environments. Engineered for mission-critical applications such as oil and gas processing, chemical manufacturing, and power generation, this unit supports the robust power requirements of the DeltaV hardware infrastructure.

Features

• Designed specifically for integration with the Emerson DeltaV S-series and CHARMs hardware.
• Provides stable, regulated power conversion for system backplanes.
• Ruggedized construction suitable for harsh industrial environments.
• Features conformal coating to protect against corrosive airborne contaminants (ISA-S71.04-1985 Class G3).
• Supports high-availability system configurations.

Applications

This power supply module is intended for use in DeltaV S-series distributed control systems (DCS). It is commonly deployed in process automation environments where reliable power delivery is required for continuous operation, including refineries, petrochemical plants, and offshore platforms.

Technical Specifications

Installation Guidelines

• Safety Warning: This module is not hot-swappable. Ensure the system power is completely de-energized before attempting to install or remove the module from the backplane.
• Handling: Use proper ESD (Electrostatic Discharge) protection when handling the module to prevent damage to sensitive internal components.
• Mounting: Ensure the module is fully seated and secured in the designated DeltaV S-series carrier slot to maintain proper electrical contact and structural integrity.
• Environment: Ensure the installation area meets the specified temperature and humidity ratings. Maintain adequate ventilation around the control cabinet to prevent heat buildup.
• Grounding: Follow standard industrial grounding practices for the DeltaV cabinet to ensure electromagnetic compatibility and safety.

FAQ

Is this module compatible with all DeltaV systems?

This module is specifically designed for the DeltaV S-series hardware infrastructure. It is not compatible with earlier DeltaV M-series or other non-S-series architectures.

Can I replace this module while the system is running?

No, this module is not hot-swappable. You must power down the system before removing or inserting the module to avoid electrical damage or system disruption.

What does the G3 conformal coating protect against?

The ISA-S71.04-1985 Class G3 rating indicates that the module is protected against severe corrosive airborne contaminants, making it suitable for use in harsh industrial environments where sulfur or other corrosive gases may be present.
