Foxboro P0914XB I/A Series 8-Slot Baseplate Chassis

Foxboro P0914XB I/A Series 8-Slot Baseplate Chassis

Description

The Foxboro P0914XB is a foundational hardware component within the I/A Series distributed control system (DCS). This 8-slot baseplate chassis provides the necessary physical mounting and electrical backplane connectivity for...

28 la gente está viendo esto ahora mismo

Disponibilidad: Bajas existencias: quedan 4

SKU: P0914XB
Proveedora: Foxboro
tipo: DCS Baseplate Chassis
Related Series:

Envíos y devoluciones

Entrega confiable a nivel mundial

  • Transportistas: Envíos a través de DHL, FedEx, UPS o USPS .
  • Envío: Los pedidos se procesan en 1-2 días hábiles y se envían dentro de 3-5 días hábiles .
  • Seguimiento: Detalles completos de seguimiento proporcionados por correo electrónico después del envío.

Garantía de devolución de dinero de 30 días

  • Garantía: período de devolución de 30 días para productos en stock y sellados de fábrica.
  • Condición: Los artículos deben estar sin abrir, sin usar y en su embalaje original.
  • Autenticidad: Garantizamos hardware 100% original y auténtico.

¿Necesitas más información? Consulta nuestra Política de envíos y reembolsos completa.

Autenticidad y garantía

  • Garantía genuina: Suministramos únicamente piezas de automatización industrial 100% originales, nuevas y selladas de fábrica .
  • Cobertura total: cada componente está respaldado por una garantía integral de 12 meses a partir de la fecha de compra.
  • Trazabilidad: Todos los productos se entregan con documentación original de fábrica y accesorios para un pleno cumplimiento industrial.

Soporte técnico y abastecimiento

  • Asistencia de expertos: Nuestro equipo técnico ofrece consulta gratuita para ayudarle a verificar la compatibilidad de los sistemas DCS y PLC.
  • Abastecimiento de piezas raras: nos especializamos en componentes obsoletos y difíciles de encontrar de Allen-Bradley, Siemens, ABB, HIMA y más.
  • Consultas al por mayor: contáctenos en pambo@5gplc.com para obtener precios por volumen o cotizaciones de proyectos personalizados.
Ver todos los detalles

Description

The Foxboro P0914XB is a foundational hardware component within the I/A Series distributed control system (DCS). This 8-slot baseplate chassis provides the necessary physical mounting and electrical backplane connectivity for high-performance Fieldbus Modules (FBMs). Engineered for mission-critical industrial applications, including oil refining, power generation, and chemical processing, the P0914XB ensures robust signal integrity and reliable power distribution. It supports hot-swappable module replacement and redundant communication paths, helping to minimize unscheduled downtime and maintain continuous process visibility in demanding environments.

Features

  • 8-slot configuration for high-density I/O deployment.
  • Supports redundant 2 Mbps HDLC Fieldbus communication.
  • Integrated power busing with transient protection for reliable DC distribution.
  • Designed for high-speed data exchange between FBMs and control workstations.
  • Supports hot-swappable module installation and removal.
  • Robust construction suitable for harsh industrial cabinet environments.

Applications

The P0914XB baseplate is utilized in Foxboro I/A Series control systems for large-scale process automation, including:

  • Oil and gas refinery process control.
  • Power generation plant monitoring and management.
  • Chemical and petrochemical processing facilities.
  • Water and wastewater treatment automation.

Technical Specifications

Brand Foxboro (Invensys / Schneider Electric)
Model P0914XB
Series I/A Series
Module Type 8-Slot Baseplate Chassis
Slot Count 8 FBM Positions
Communication Interface Redundant Fieldbus
Input Voltage 24 VDC
Operating Temperature 0 to 60 deg C
Storage Temperature -40 to 85 deg C
Relative Humidity 5 to 95 percent (Non-condensing)
Mounting DIN Rail or Plate Mount

Installation Guidelines

  • Ensure the mounting surface is clean, level, and capable of supporting the weight of the chassis and installed modules.
  • The chassis may be mounted vertically or horizontally within a standard industrial enclosure.
  • Ensure adequate clearance around the unit for proper ventilation and heat dissipation.
  • Verify that all power is disconnected before installing or removing the baseplate or any FBM modules.
  • Use shielded cables for Fieldbus communication to minimize EMI/RFI interference.
  • Ensure proper grounding of the chassis to the cabinet ground bus to maintain signal integrity and safety.
  • Handle modules with care to prevent electrostatic discharge (ESD) damage to sensitive electronic components.

Compliance and Certifications

The P0914XB is designed to meet standard industrial requirements, including CE, UL, CSA, and ATEX Zone 2 certifications.

FAQ

Is the P0914XB compatible with all Foxboro FBMs?

The P0914XB is designed for use with standard Foxboro I/A Series Fieldbus Modules. Please verify the specific compatibility of your FBM model with the I/A Series documentation.

Does this chassis support redundant power supplies?

Yes, the baseplate is designed to support the redundant power distribution requirements of the I/A Series architecture.
