General Electric IC697CPU771 Series 90-70 Central Processing Unit

General Electric IC697CPU771 Series 90-70 Central Processing Unit

Description

The General Electric IC697CPU771 is a high-performance Central Processing Unit (CPU) module designed for the Series 90-70 Programmable Logic Controller (PLC) platform. Featuring an embedded 80C186 microprocessor operating at 12...

29 la gente está viendo esto ahora mismo

Disponibilidad: Bajas existencias: quedan 6

SKU: IC697CPU771
Proveedora: General Electric
tipo: PLC CPU Module
Related Series:

Envíos y devoluciones

Entrega confiable a nivel mundial

  • Transportistas: Envíos a través de DHL, FedEx, UPS o USPS .
  • Envío: Los pedidos se procesan en 1-2 días hábiles y se envían dentro de 3-5 días hábiles .
  • Seguimiento: Detalles completos de seguimiento proporcionados por correo electrónico después del envío.

Garantía de devolución de dinero de 30 días

  • Garantía: período de devolución de 30 días para productos en stock y sellados de fábrica.
  • Condición: Los artículos deben estar sin abrir, sin usar y en su embalaje original.
  • Autenticidad: Garantizamos hardware 100% original y auténtico.

¿Necesitas más información? Consulta nuestra Política de envíos y reembolsos completa.

Autenticidad y garantía

  • Garantía genuina: Suministramos únicamente piezas de automatización industrial 100% originales, nuevas y selladas de fábrica .
  • Cobertura total: cada componente está respaldado por una garantía integral de 12 meses a partir de la fecha de compra.
  • Trazabilidad: Todos los productos se entregan con documentación original de fábrica y accesorios para un pleno cumplimiento industrial.

Soporte técnico y abastecimiento

  • Asistencia de expertos: Nuestro equipo técnico ofrece consulta gratuita para ayudarle a verificar la compatibilidad de los sistemas DCS y PLC.
  • Abastecimiento de piezas raras: nos especializamos en componentes obsoletos y difíciles de encontrar de Allen-Bradley, Siemens, ABB, HIMA y más.
  • Consultas al por mayor: contáctenos en pambo@5gplc.com para obtener precios por volumen o cotizaciones de proyectos personalizados.
Ver todos los detalles

Description

The General Electric IC697CPU771 is a high-performance Central Processing Unit (CPU) module designed for the Series 90-70 Programmable Logic Controller (PLC) platform. Featuring an embedded 80C186 microprocessor operating at 12 MHz, this module delivers a Boolean execution time of 0.4 microseconds per function. It serves as the primary controller for industrial automation, managing real-time control of machinery, material handling systems, and complex process automation.

Features

  • 12 MHz 80C186 microprocessor architecture.
  • Supports up to 2K discrete inputs and outputs (any mix).
  • Supports up to 8K analog I/O points.
  • 0.4 microseconds per Boolean function execution speed.
  • Software-based configuration (no physical DIP switches or jumpers required).
  • Three-position operation mode switch for manual control.
  • Battery-backed calendar clock for time-stamping and scheduling.
  • Three integrated status LED indicators: Module OK, Run, and Outputs Enabled.
  • Compatible with VME C.1 Standard format backplanes (IC697CHS750, 782, 783, 790, 791).

Applications

  • Gas Turbine Control Systems
  • Industrial Process Control and Automation
  • Water Treatment Plant Management
  • Automotive Assembly and Robotics
  • Power Generation and Grid Control

Technical Specifications

Model IC697CPU771
Processor 80C186 (12 MHz)
Discrete I/O Memory 2 KB
Analog I/O Memory 8 KB
Max RAM 512 KB (Expansion supported)
Communication RS-485 Interface
Mounting Single slot, Rack 0
Manufacturer General Electric

Installation Guidelines

  • Ensure the PLC rack is powered down before inserting or removing the CPU module to prevent electrical damage.
  • The module is designed for installation in slot 1 of the primary rack (Rack 0).
  • Handle the module using ESD-safe practices to protect internal circuitry.
  • Ensure proper ventilation within the cabinet; maintain clearance around the rack to prevent overheating.
  • Use shielded cabling for RS-485 communication to minimize EMI interference from high-voltage equipment.
  • Verify that the backplane connectors are clean and free of debris before seating the module.

FAQs

What is the GE IC697CPU771?

The GE IC697CPU771 is a 12MHz, single-slot CPU module for the GE Fanuc Series 90-70 PLC system, supporting up to 2K discrete I/O and 8K analog I/O.

What is the difference between IC697CPU771 and IC697CPU772?

Both are 12MHz modules with 2K discrete I/O capacity, but the IC697CPU772 features floating-point mathematics, whereas the IC697CPU771 does not.

What is the memory capability of the IC697CPU771?

It supports up to 512 Kbytes of battery-backed expansion memory for user and program data storage.

What software is used to configure it?

The unit is configured via Logicmaster 90-70, VersaPro, or Proficy Machine Edition software.
