General Electric DS200TBQBG1ACB Mark VIe Input Termination Board

General Electric DS200TBQBG1ACB Mark VIe Input Termination Board

The General Electric DS200TBQBG1ACB is an input termination board designed for use within the Mark VIe control system architecture. This component serves as a critical interface for analog signal processing,...

23 la gente está viendo esto ahora mismo

Disponibilidad: Bajas existencias: quedan 10

SKU: DS200TBQBG1ACB
Proveedora: General Electric
tipo: Termination Board
Related Series:

Envíos y devoluciones

Entrega confiable a nivel mundial

  • Transportistas: Envíos a través de DHL, FedEx, UPS o USPS .
  • Envío: Los pedidos se procesan en 1-2 días hábiles y se envían dentro de 3-5 días hábiles .
  • Seguimiento: Detalles completos de seguimiento proporcionados por correo electrónico después del envío.

Garantía de devolución de dinero de 30 días

  • Garantía: período de devolución de 30 días para productos en stock y sellados de fábrica.
  • Condición: Los artículos deben estar sin abrir, sin usar y en su embalaje original.
  • Autenticidad: Garantizamos hardware 100% original y auténtico.

¿Necesitas más información? Consulta nuestra Política de envíos y reembolsos completa.

Autenticidad y garantía

  • Garantía genuina: Suministramos únicamente piezas de automatización industrial 100% originales, nuevas y selladas de fábrica .
  • Cobertura total: cada componente está respaldado por una garantía integral de 12 meses a partir de la fecha de compra.
  • Trazabilidad: Todos los productos se entregan con documentación original de fábrica y accesorios para un pleno cumplimiento industrial.

Soporte técnico y abastecimiento

  • Asistencia de expertos: Nuestro equipo técnico ofrece consulta gratuita para ayudarle a verificar la compatibilidad de los sistemas DCS y PLC.
  • Abastecimiento de piezas raras: nos especializamos en componentes obsoletos y difíciles de encontrar de Allen-Bradley, Siemens, ABB, HIMA y más.
  • Consultas al por mayor: contáctenos en pambo@5gplc.com para obtener precios por volumen o cotizaciones de proyectos personalizados.
Ver todos los detalles

The General Electric DS200TBQBG1ACB is an input termination board designed for use within the Mark VIe control system architecture. This component serves as a critical interface for analog signal processing, facilitating the connection and routing of field signals to the control system hardware. As a legacy component, it is specifically engineered to handle high-density analog input requirements in industrial automation environments.

Features

  • Designed for R-S-T analog signal termination in Mark VIe systems.
  • Features a 78-way interface configuration for high-density connectivity.
  • Supports standard industrial analog signals including 4-20 mA and +/- 10 V ranges.
  • Provides 500 Vdc channel-to-earth isolation to ensure signal integrity and protection.
  • Optimized for reliable operation in demanding temperature ranges from -20 degC to +70 degC.

Technical Specifications

Model Number DS200TBQBG1ACB
Spare Model DS200TBQBG1A
Function Analog Input Termination Board
Signal Support 4-20 mA / +/- 10 V
Isolation 500 Vdc (Channel-to-Earth)
Max Cable Length 90 m
Operating Temperature -20 degC to +70 degC
Storage Temperature -40 degC to +85 degC
Humidity 95% RH (non-condensing)

Installation Guidelines

  • Ensure the control system is fully powered down before installing or removing the termination board to prevent electrical damage.
  • Handle the board using proper ESD (Electrostatic Discharge) mitigation techniques to protect sensitive internal circuitry.
  • Verify that all field wiring is properly secured to the 78-way terminal blocks to maintain signal continuity.
  • Maintain proper cable routing practices, keeping signal lines away from high-voltage power cables to minimize EMI interference.
  • Ensure the installation environment is within the specified humidity and temperature limits to prevent condensation and thermal stress.

FAQ

Is this board compatible with the Mark V system? While the board is associated with Mark V/VIe system architectures, please verify your specific controller revision and hardware compatibility before installation.

What is the maximum signal cable length for this board? The board is rated for signal cabling up to 90 meters, provided that appropriate shielding and grounding practices are followed.
