General Electric IS220PTCCH1B Mark VIe Thermocouple Input Module

General Electric IS220PTCCH1B Mark VIe Thermocouple Input Module

The IS220PTCCH1B is a specialized Thermocouple Input I/O pack designed for the General Electric Mark VIe Speedtronic control system. This module provides high-precision signal acquisition for various thermocouple sensor types,...

18 la gente está viendo esto ahora mismo

Disponibilidad: Bajas existencias: quedan 3

SKU: IS220PTCCH1B
Proveedora: General Electric
tipo: Thermocouple Input Module
Related Series:

Envíos y devoluciones

Entrega confiable a nivel mundial

  • Transportistas: Envíos a través de DHL, FedEx, UPS o USPS .
  • Envío: Los pedidos se procesan en 1-2 días hábiles y se envían dentro de 3-5 días hábiles .
  • Seguimiento: Detalles completos de seguimiento proporcionados por correo electrónico después del envío.

Garantía de devolución de dinero de 30 días

  • Garantía: período de devolución de 30 días para productos en stock y sellados de fábrica.
  • Condición: Los artículos deben estar sin abrir, sin usar y en su embalaje original.
  • Autenticidad: Garantizamos hardware 100% original y auténtico.

¿Necesitas más información? Consulta nuestra Política de envíos y reembolsos completa.

Autenticidad y garantía

  • Garantía genuina: Suministramos únicamente piezas de automatización industrial 100% originales, nuevas y selladas de fábrica .
  • Cobertura total: cada componente está respaldado por una garantía integral de 12 meses a partir de la fecha de compra.
  • Trazabilidad: Todos los productos se entregan con documentación original de fábrica y accesorios para un pleno cumplimiento industrial.

Soporte técnico y abastecimiento

  • Asistencia de expertos: Nuestro equipo técnico ofrece consulta gratuita para ayudarle a verificar la compatibilidad de los sistemas DCS y PLC.
  • Abastecimiento de piezas raras: nos especializamos en componentes obsoletos y difíciles de encontrar de Allen-Bradley, Siemens, ABB, HIMA y más.
  • Consultas al por mayor: contáctenos en pambo@5gplc.com para obtener precios por volumen o cotizaciones de proyectos personalizados.
Ver todos los detalles

The IS220PTCCH1B is a specialized Thermocouple Input I/O pack designed for the General Electric Mark VIe Speedtronic control system. This module provides high-precision signal acquisition for various thermocouple sensor types, facilitating reliable temperature monitoring in demanding industrial environments such as gas turbine control applications.

Features

  • 12 differential input channels for high-density thermocouple signal processing.
  • Supports a wide range of thermocouple types including J, K, E, T, R, S, and B.
  • Integrated 16-bit ADC for high-resolution data conversion.
  • Robust 1500 V DC isolation to protect sensitive control electronics from common-mode noise and surges.
  • Designed for high-reliability operation within the Mark VIe control architecture.

Applications

This I/O pack is primarily utilized in power generation and industrial automation settings where precise temperature measurement is critical. It is specifically engineered for integration with Speedtronic Mark VIe turbine control systems, providing the necessary interface between field-mounted thermocouples and the central control processor.

Technical Specifications

Model IS220PTCCH1B
Manufacturer General Electric
Input Channels 12 Differential
Sensor Compatibility J, K, E, T, R, S, B
ADC Resolution 16-bit
Power Supply 28 VDC (0.16 A)
Power Consumption ≤ 2.4 W
Isolation 1500 V DC
Operating Temperature -40 degC to +85 degC
Storage Temperature -55 degC to +90 degC
Humidity 5% to 95% RH (non-condensing)

Installation Guidelines

  • Ensure the control system is powered down before installing or removing the I/O pack to prevent electrical damage.
  • Verify that the module is correctly seated in the designated Mark VIe terminal board slot.
  • Maintain proper grounding practices to minimize electromagnetic interference (EMI) and ensure signal integrity.
  • Use shielded cabling for all thermocouple inputs to reduce the risk of noise pickup in high-EMI industrial environments.
  • Ensure adequate ventilation in the cabinet to maintain ambient temperatures within the specified operating range.

FAQ

What is the primary function of the IS220PTCCH1B?
It serves as a thermocouple input interface for the Mark VIe control system, converting analog temperature signals from field sensors into digital data for the controller.

Can this module be used in extreme temperatures?
Yes, the module is rated for an operating temperature range of -40 degC to +85 degC, making it suitable for harsh industrial environments.

Does this module require external power?
The module operates on a 28 VDC power supply provided through the Mark VIe I/O rack backplane.
