General Electric PACSystems RX3i IC695PNS001 PROFINET Scanner Module

General Electric PACSystems RX3i IC695PNS001 PROFINET Scanner Module

The IC695PNS001 is a high-performance PROFINET Scanner (PNS) module designed for the GE PACSystems RX3i platform. This module serves as the critical interface between a PROFINET I/O controller and remote...

23 la gente está viendo esto ahora mismo

Disponibilidad: Bajas existencias: quedan 8

SKU: IC695PNS001
Proveedora: General Electric
tipo: PROFINET Scanner Module
Related Series:

Envíos y devoluciones

Entrega confiable a nivel mundial

  • Transportistas: Envíos a través de DHL, FedEx, UPS o USPS .
  • Envío: Los pedidos se procesan en 1-2 días hábiles y se envían dentro de 3-5 días hábiles .
  • Seguimiento: Detalles completos de seguimiento proporcionados por correo electrónico después del envío.

Garantía de devolución de dinero de 30 días

  • Garantía: período de devolución de 30 días para productos en stock y sellados de fábrica.
  • Condición: Los artículos deben estar sin abrir, sin usar y en su embalaje original.
  • Autenticidad: Garantizamos hardware 100% original y auténtico.

¿Necesitas más información? Consulta nuestra Política de envíos y reembolsos completa.

Autenticidad y garantía

  • Garantía genuina: Suministramos únicamente piezas de automatización industrial 100% originales, nuevas y selladas de fábrica .
  • Cobertura total: cada componente está respaldado por una garantía integral de 12 meses a partir de la fecha de compra.
  • Trazabilidad: Todos los productos se entregan con documentación original de fábrica y accesorios para un pleno cumplimiento industrial.

Soporte técnico y abastecimiento

  • Asistencia de expertos: Nuestro equipo técnico ofrece consulta gratuita para ayudarle a verificar la compatibilidad de los sistemas DCS y PLC.
  • Abastecimiento de piezas raras: nos especializamos en componentes obsoletos y difíciles de encontrar de Allen-Bradley, Siemens, ABB, HIMA y más.
  • Consultas al por mayor: contáctenos en pambo@5gplc.com para obtener precios por volumen o cotizaciones de proyectos personalizados.
Ver todos los detalles

The IC695PNS001 is a high-performance PROFINET Scanner (PNS) module designed for the GE PACSystems RX3i platform. This module serves as the critical interface between a PROFINET I/O controller and remote RX3i universal I/O racks, facilitating seamless data exchange and network management across industrial automation environments.

Features

  • Connects remote RX3i I/O racks to PROFINET IO-Controllers.
  • Four switched Ethernet ports: two RJ-45 (10/100/1000 Mbps) and two SFP cages for flexible media support.
  • Supports daisy-chain, star, and ring (MRP) network topologies.
  • Integrated SD card slot for IO-Device name transfer and configuration backup.
  • USB Micro-B port for firmware updates via WinLoader.
  • Provides 32 input status bits and 32 output control bits for system diagnostics.

Applications

  • Distributed I/O: Enables remote backplane connectivity for RX3i and legacy Series 90-30 I/O.
  • Plant Control: Integrates field devices with PACSystems CPUs including CPE305, CPE310, CPU315, and CPU320.
  • High-Availability Systems: Supports redundant media topologies for critical manufacturing processes.
  • Long-Distance Networking: Fiber optic capability via SFP modules for geographically dispersed facilities.

Technical Specifications

Model IC695PNS001
Series PACSystems RX3i
Power Requirements 3.3V DC @ 1.2A or 5V DC @ 1.1A
Operating Temperature 0 to 60 degC
Storage Temperature -40 to 85 degC
Ethernet Ports 4 (2x RJ-45, 2x SFP)
Slot Requirement 1 Slot
Software Requirement Proficy Machine Edition 8.50 SIM 2 or later

Installation Guidelines

  • The module must be installed within a suitable industrial enclosure to protect against live electrical parts.
  • Install in Slot 1 or 2 of an RX3i universal backplane, or Slot 6 of an RX3i 7-slot backplane.
  • Ensure power is disconnected before inserting or removing the module from the rack.
  • Use protective gloves or pliers when handling SFP modules if the ambient temperature exceeds 40 degC, as SFP devices may reach temperatures above 70 degC.
  • Keep protective covers on all unused SFP ports to prevent debris ingress.
  • Assign an I/O Device Name using a DCP tool (e.g., Proficy Machine Edition Discovery Tool) prior to network operation.

FAQ

How many Ethernet ports are available on the IC695PNS001?

The module features four Ethernet ports: two 8-conductor RJ-45 ports for copper connections and two SFP cages for user-supplied fiber or copper SFP transceivers.

What network topologies are supported?

The module supports flexible network architectures including linear, star, daisy-chain, and ring (redundant media) topologies.

What is the purpose of the USB port?

The USB Micro-B port is dedicated to firmware updates using the WinLoader utility. It is not intended for permanent connection or standard data communication.

Can I replace the module without re-configuring via software?

Yes, the module supports the transfer of the IO-Device Name to a new unit using an SD card, which simplifies replacement procedures in the field.
