Honeywell 8U-IP0102 PROFIBUS Gateway Module

Honeywell 8U-IP0102 PROFIBUS Gateway Module

Description

The Honeywell 8U-IP0102 is a high-performance PROFIBUS gateway module engineered for seamless integration within Honeywell Experion PKS and C300 control system architectures. This module serves as a critical interface, facilitating...

16 la gente está viendo esto ahora mismo

Disponibilidad: Bajas existencias: quedan 4

SKU: 8U-IP0102
Proveedora: Honeywell
tipo: PROFIBUS Gateway Module
Related Series:

Envíos y devoluciones

Entrega confiable a nivel mundial

  • Transportistas: Envíos a través de DHL, FedEx, UPS o USPS .
  • Envío: Los pedidos se procesan en 1-2 días hábiles y se envían dentro de 3-5 días hábiles .
  • Seguimiento: Detalles completos de seguimiento proporcionados por correo electrónico después del envío.

Garantía de devolución de dinero de 30 días

  • Garantía: período de devolución de 30 días para productos en stock y sellados de fábrica.
  • Condición: Los artículos deben estar sin abrir, sin usar y en su embalaje original.
  • Autenticidad: Garantizamos hardware 100% original y auténtico.

¿Necesitas más información? Consulta nuestra Política de envíos y reembolsos completa.

Autenticidad y garantía

  • Garantía genuina: Suministramos únicamente piezas de automatización industrial 100% originales, nuevas y selladas de fábrica .
  • Cobertura total: cada componente está respaldado por una garantía integral de 12 meses a partir de la fecha de compra.
  • Trazabilidad: Todos los productos se entregan con documentación original de fábrica y accesorios para un pleno cumplimiento industrial.

Soporte técnico y abastecimiento

  • Asistencia de expertos: Nuestro equipo técnico ofrece consulta gratuita para ayudarle a verificar la compatibilidad de los sistemas DCS y PLC.
  • Abastecimiento de piezas raras: nos especializamos en componentes obsoletos y difíciles de encontrar de Allen-Bradley, Siemens, ABB, HIMA y más.
  • Consultas al por mayor: contáctenos en pambo@5gplc.com para obtener precios por volumen o cotizaciones de proyectos personalizados.
Ver todos los detalles

Description

The Honeywell 8U-IP0102 is a high-performance PROFIBUS gateway module engineered for seamless integration within Honeywell Experion PKS and C300 control system architectures. This module serves as a critical interface, facilitating protocol conversion between PROFIBUS DP or PROFIBUS PA field networks and Ethernet-based control infrastructures. By enabling deterministic, real-time data exchange, the 8U-IP0102 allows operators to incorporate distributed field devices into centralized DCS environments, effectively bridging legacy fieldbus technology with modern Ethernet control systems to enhance plant availability and simplify system migrations.

Features

  • Protocol Versatility: Supports both PROFIBUS DP for high-speed discrete/analog I/O and PROFIBUS PA for process instrumentation.
  • Seamless Integration: Designed for direct connectivity with Honeywell Experion PKS and C300 controllers via Ethernet.
  • Deterministic Performance: Manages both cyclic and acyclic data exchange to ensure consistent communication timing and reliable process data transfer.
  • Industrial Design: Robust construction suitable for standard industrial control cabinet mounting.

Applications

The 8U-IP0102 is ideal for complex industrial environments where legacy fieldbus devices must be integrated into modern, Ethernet-enabled control systems. Typical applications include oil and gas processing, power generation facilities, and large-scale building automation systems requiring high-reliability data communication.

Technical Specifications

Model 8U-IP0102
Supply Voltage 24 VDC
Current Consumption 430 mA
Power Consumption 10 W
Operating Temperature 0 to 60 deg C
Storage Temperature -40 to 85 deg C
Protocols PROFIBUS DP, PROFIBUS PA, Ethernet TCP/IP

Installation Guidelines

  • Mounting: Designed for rack or panel mounting within standard industrial control cabinets. Ensure adequate clearance for airflow.
  • Power Requirements: Ensure a stable 24 VDC power supply. Verify polarity before connection to prevent module damage.
  • Handling: Observe standard ESD (Electrostatic Discharge) precautions when handling the module to prevent damage to internal circuitry.
  • Environment: Intended for use in controlled industrial environments. Protect from excessive moisture, dust, and corrosive gases.
  • Wiring: Use shielded communication cables for PROFIBUS and Ethernet connections to minimize EMI interference. Route signal cables away from high-voltage power lines.
  • Maintenance: Always power down the module before insertion or removal from the rack or backplane.

FAQ

What control systems is the 8U-IP0102 compatible with?

The 8U-IP0102 is specifically designed for integration with Honeywell Experion PKS and C300 control systems.

Does this module support both PROFIBUS DP and PA?

Yes, the module is capable of handling both PROFIBUS DP for discrete/analog I/O and PROFIBUS PA for process instrumentation, acting as a gateway to the Ethernet control network.

What is the power requirement for this module?

The module operates on 24 VDC and has a power consumption of approximately 10 W.
