Honeywell MC-PC1X02 Differential Pressure Transducer

Honeywell MC-PC1X02 Differential Pressure Transducer

Description

The Honeywell MC-PC1X02 is a high-precision differential pressure transducer designed for demanding industrial process automation environments. This device provides reliable, low-pressure monitoring with a measurement range of +/- 125 psi...

20 la gente está viendo esto ahora mismo

Disponibilidad: Bajas existencias: quedan 4

SKU: MC-PC1X02
Proveedora: Honeywell
tipo: Differential Pressure Transducer
Related Series:

Envíos y devoluciones

Entrega confiable a nivel mundial

  • Transportistas: Envíos a través de DHL, FedEx, UPS o USPS .
  • Envío: Los pedidos se procesan en 1-2 días hábiles y se envían dentro de 3-5 días hábiles .
  • Seguimiento: Detalles completos de seguimiento proporcionados por correo electrónico después del envío.

Garantía de devolución de dinero de 30 días

  • Garantía: período de devolución de 30 días para productos en stock y sellados de fábrica.
  • Condición: Los artículos deben estar sin abrir, sin usar y en su embalaje original.
  • Autenticidad: Garantizamos hardware 100% original y auténtico.

¿Necesitas más información? Consulta nuestra Política de envíos y reembolsos completa.

Autenticidad y garantía

  • Garantía genuina: Suministramos únicamente piezas de automatización industrial 100% originales, nuevas y selladas de fábrica .
  • Cobertura total: cada componente está respaldado por una garantía integral de 12 meses a partir de la fecha de compra.
  • Trazabilidad: Todos los productos se entregan con documentación original de fábrica y accesorios para un pleno cumplimiento industrial.

Soporte técnico y abastecimiento

  • Asistencia de expertos: Nuestro equipo técnico ofrece consulta gratuita para ayudarle a verificar la compatibilidad de los sistemas DCS y PLC.
  • Abastecimiento de piezas raras: nos especializamos en componentes obsoletos y difíciles de encontrar de Allen-Bradley, Siemens, ABB, HIMA y más.
  • Consultas al por mayor: contáctenos en pambo@5gplc.com para obtener precios por volumen o cotizaciones de proyectos personalizados.
Ver todos los detalles

Description

The Honeywell MC-PC1X02 is a high-precision differential pressure transducer designed for demanding industrial process automation environments. This device provides reliable, low-pressure monitoring with a measurement range of +/- 125 psi (+/- 8.62 bar). It is engineered to deliver a stable 4-20 mA analog output, ensuring seamless integration with Distributed Control Systems (DCS), Programmable Logic Controllers (PLC), and SCADA platforms. Designed for longevity and accuracy, the MC-PC1X02 features low annual drift, which minimizes the need for frequent recalibration and helps maintain consistent process control.

Features

  • High Precision Sensing: Optimized for stable differential pressure measurement under fluctuating industrial load conditions.
  • Analog Output: Standard 4-20 mA current loop signal for noise-resistant, long-distance transmission.
  • Robust Construction: Housed in durable Polyphenylene Sulfide (PPS) with an IP66 enclosure rating for protection against moisture, vibration, and corrosive atmospheres.
  • Low Drift: Long-term stability rated at +/- 0.1 percent full scale per year.
  • Flexible Power: Operates on a wide 12 to 30 VDC supply range with low power consumption.

Applications

The MC-PC1X02 is suitable for a variety of industrial applications, including:

  • Refinery process skids
  • Boiler and steam management systems
  • Gas compression stations
  • Water treatment and filtration plants
  • HVAC process control and monitoring

Technical Specifications

Model MC-PC1X02
Pressure Range +/- 125 psi (+/- 8.62 bar)
Accuracy +/- 0.05 percent full scale
Long-Term Stability +/- 0.1 percent full scale per year
Output Signal 4-20 mA
Supply Voltage 12 to 30 VDC
Power Consumption 5 mA
Housing Material Polyphenylene Sulfide (PPS)
Electrical Connection 1/2 inch NPT
Process Connection 1/4 inch NPT
Enclosure Rating IP66
Operating Temperature -20 to 60 deg C
Storage Temperature -40 to 85 deg C

Installation Guidelines

  • Mounting: Ensure the transducer is mounted securely using the provided threaded connections. Avoid high-vibration zones if possible, or use appropriate dampening mounts.
  • Wiring: Use shielded twisted-pair cabling for the 4-20 mA loop to prevent electromagnetic interference (EMI) from nearby high-voltage lines or variable frequency drives.
  • Sealing: Ensure 1/4 inch NPT process ports are properly sealed using compatible thread sealant to prevent leaks in high-pressure or hazardous media applications.
  • Power: Verify that the supply voltage is within the 12-30 VDC range before applying power.
  • Handling: As a precision instrument, handle with care to avoid mechanical shock to the sensing diaphragm.

FAQ

What is the primary output signal of the MC-PC1X02?

The transducer provides a standard 4-20 mA analog current loop output, which is ideal for long-distance signal transmission in industrial environments.

What is the IP rating of this device?

The MC-PC1X02 is rated IP66, providing robust protection against dust ingress and powerful water jets, making it suitable for harsh industrial environments.

Can this transducer be used in corrosive atmospheres?

Yes, the housing is constructed from Polyphenylene Sulfide (PPS), which offers excellent chemical resistance, making it suitable for many corrosive industrial settings.
