ProSoft MVI46-MCM Modbus Master/Slave Communication Module

ProSoft MVI46-MCM Modbus Master/Slave Communication Module

Description

The ProSoft MVI46-MCM is a high-performance communication module designed to allow Rockwell Automation SLC 500 processors to interface seamlessly with Modbus protocol-compatible devices. Acting as an input/output module between the...

29 la gente está viendo esto ahora mismo

Disponibilidad: Bajas existencias: quedan 3

SKU: MVI46-MCM
Proveedora: ProSoft
tipo: Communication Module
Related Series:

Envíos y devoluciones

Entrega confiable a nivel mundial

  • Transportistas: Envíos a través de DHL, FedEx, UPS o USPS .
  • Envío: Los pedidos se procesan en 1-2 días hábiles y se envían dentro de 3-5 días hábiles .
  • Seguimiento: Detalles completos de seguimiento proporcionados por correo electrónico después del envío.

Garantía de devolución de dinero de 30 días

  • Garantía: período de devolución de 30 días para productos en stock y sellados de fábrica.
  • Condición: Los artículos deben estar sin abrir, sin usar y en su embalaje original.
  • Autenticidad: Garantizamos hardware 100% original y auténtico.

¿Necesitas más información? Consulta nuestra Política de envíos y reembolsos completa.

Autenticidad y garantía

  • Garantía genuina: Suministramos únicamente piezas de automatización industrial 100% originales, nuevas y selladas de fábrica .
  • Cobertura total: cada componente está respaldado por una garantía integral de 12 meses a partir de la fecha de compra.
  • Trazabilidad: Todos los productos se entregan con documentación original de fábrica y accesorios para un pleno cumplimiento industrial.

Soporte técnico y abastecimiento

  • Asistencia de expertos: Nuestro equipo técnico ofrece consulta gratuita para ayudarle a verificar la compatibilidad de los sistemas DCS y PLC.
  • Abastecimiento de piezas raras: nos especializamos en componentes obsoletos y difíciles de encontrar de Allen-Bradley, Siemens, ABB, HIMA y más.
  • Consultas al por mayor: contáctenos en pambo@5gplc.com para obtener precios por volumen o cotizaciones de proyectos personalizados.
Ver todos los detalles

Description

The ProSoft MVI46-MCM is a high-performance communication module designed to allow Rockwell Automation SLC 500 processors to interface seamlessly with Modbus protocol-compatible devices. Acting as an input/output module between the Modbus network and the Allen-Bradley backplane, it facilitates asynchronous data exchange. The module features a 5000-word register space for efficient data transfer, supporting both Master and Slave configurations across its communication ports.

Features

  • Dual-port interface supporting RS-232, RS-422, or RS-485 physical layers.
  • Configurable as a Modbus Master or Slave device.
  • Supports up to 100 commands per port in Master mode.
  • Optimized polling characteristics to manage communication with problematic slave nodes.
  • Direct ladder logic control for command execution.
  • Single-slot module design for Allen-Bradley 1746 chassis.

Applications

  • SCADA system integration and data concentration.
  • Pulp and paper mill process control and motor drive management.
  • Mining and heavy material handling, including conveyor and crushing equipment.
  • Burner and boiler management systems.
  • Food and beverage processing, including weigh scales and temperature controllers.
  • Automotive manufacturing, including robotic welding and CNC station monitoring.

Technical Specifications

Product Model MVI46-MCM
Manufacturer ProSoft Technology
Backplane Current Load 800 mA at 5.1 VDC
Operating Temperature 0 to 60 degC (32 to 140 degF)
Storage Temperature -40 to 85 degC (-40 to 185 degF)
Relative Humidity 5 to 95% (non-condensing)
Vibration 5 g from 10-150 Hz
Module Width Single slot
Compatible Rack Allen-Bradley 1746 chassis

Installation Guidelines

  • Ensure the SLC 500 processor is powered down before inserting or removing the module from the chassis.
  • The module must be installed in a local or extended I/O rack (0-3) of the SLC 500 system; it does not support remote I/O rack installation.
  • Use appropriate shielded cabling for RS-422/485 connections to minimize EMI interference.
  • Ensure proper grounding of the chassis to maintain signal integrity.
  • Follow standard ESD precautions when handling the module to prevent damage to internal circuitry.

FAQs

What is the MVI46-MCM?

The ProSoft Technology MVI46-MCM is a Modbus Communication Module for Allen-Bradley SLC 500 systems, supporting Master or Slave protocols on two configurable serial ports.

Can the MVI46-MCM be placed in a remote rack?

No, it must reside in the local or extended I/O rack (0-3) of the SLC 500 system.

What is the difference between MVI46-MCM and 3150-MCM?

The MVI46-MCM is a faster, modern module supporting up to 115.2 kbps and 100 commands per port, whereas the 3150-MCM is a legacy version with lower performance specifications.
