ProSoft MVI69-PDPMV1 PROFIBUS DPV1 Master Communication Module

ProSoft MVI69-PDPMV1 PROFIBUS DPV1 Master Communication Module

Description

The ProSoft MVI69-PDPMV1 is a high-performance PROFIBUS DPV1 Master communication module designed specifically for integration with Rockwell Automation CompactLogix and MicroLogix 1769 platform processors. This module enables seamless data exchange...

28 la gente está viendo esto ahora mismo

Disponibilidad: Bajas existencias: quedan 6

SKU: MVI69-PDPMV1
Proveedora: ProSoft
tipo: Communication Module
Related Series:

Envíos y devoluciones

Entrega confiable a nivel mundial

  • Transportistas: Envíos a través de DHL, FedEx, UPS o USPS .
  • Envío: Los pedidos se procesan en 1-2 días hábiles y se envían dentro de 3-5 días hábiles .
  • Seguimiento: Detalles completos de seguimiento proporcionados por correo electrónico después del envío.

Garantía de devolución de dinero de 30 días

  • Garantía: período de devolución de 30 días para productos en stock y sellados de fábrica.
  • Condición: Los artículos deben estar sin abrir, sin usar y en su embalaje original.
  • Autenticidad: Garantizamos hardware 100% original y auténtico.

¿Necesitas más información? Consulta nuestra Política de envíos y reembolsos completa.

Autenticidad y garantía

  • Garantía genuina: Suministramos únicamente piezas de automatización industrial 100% originales, nuevas y selladas de fábrica .
  • Cobertura total: cada componente está respaldado por una garantía integral de 12 meses a partir de la fecha de compra.
  • Trazabilidad: Todos los productos se entregan con documentación original de fábrica y accesorios para un pleno cumplimiento industrial.

Soporte técnico y abastecimiento

  • Asistencia de expertos: Nuestro equipo técnico ofrece consulta gratuita para ayudarle a verificar la compatibilidad de los sistemas DCS y PLC.
  • Abastecimiento de piezas raras: nos especializamos en componentes obsoletos y difíciles de encontrar de Allen-Bradley, Siemens, ABB, HIMA y más.
  • Consultas al por mayor: contáctenos en pambo@5gplc.com para obtener precios por volumen o cotizaciones de proyectos personalizados.
Ver todos los detalles

Description

The ProSoft MVI69-PDPMV1 is a high-performance PROFIBUS DPV1 Master communication module designed specifically for integration with Rockwell Automation CompactLogix and MicroLogix 1769 platform processors. This module enables seamless data exchange between the PLC backplane and PROFIBUS DP slave devices, acting as a master node on the network. It is engineered to handle complex communication tasks, supporting both cyclic and acyclic data transfer as defined by the DPV1 specification.

Features

  • Supports PROFIBUS DPV1 Master functionality for advanced network control.
  • Interfaces directly with the 1769 backplane for high-speed data transfer.
  • Supports up to 125 PROFIBUS slave devices on a single network.
  • Features one isolated DB-9F RS-485 port for reliable fieldbus connectivity.
  • Designed for seamless integration with CompactLogix and MicroLogix controller architectures.

Applications

This module is widely utilized in industrial automation environments requiring the integration of PROFIBUS-enabled field devices into a Rockwell Automation control system. Common applications include motor control centers (MCCs), variable frequency drives (VFDs), remote I/O blocks, and complex instrumentation systems where DPV1 acyclic messaging is required for configuration and diagnostics.

Technical Specifications

Parameter Specification
Product Model MVI69-PDPMV1
Communication Protocol PROFIBUS DP-V1 Master
Backplane Current 800 mA @ 5 V
Slave Capacity 125 slaves max
Operating Temperature 0 degC to 60 degC (32 degF to 140 degF)
Storage Temperature -40 degC to 85 degC (-40 degF to 185 degF)
Relative Humidity 5% to 95% (non-condensing)
Power Supply Distance 2 (First 2 slots if used with 1769-L43 and -L45)

Installation Guidelines

  • Power Down: Always disconnect power from the 1769 backplane before inserting or removing the MVI69-PDPMV1 module to prevent electrical damage.
  • Slot Placement: Ensure the module is installed within the power supply distance rating specified (first 2 slots for certain controller models).
  • Mounting: Secure the module firmly into the 1769 chassis, ensuring the backplane connector is fully seated and the locking tab is engaged.
  • Grounding: Use appropriate shielded PROFIBUS cable and ensure the cable shield is properly grounded to minimize EMI interference.
  • ESD Precautions: Handle the module by the housing or edges; avoid touching the backplane pins or internal components to prevent electrostatic discharge damage.

FAQ

What is the primary function of the MVI69-PDPMV1?

The MVI69-PDPMV1 acts as a PROFIBUS Master, allowing a CompactLogix or MicroLogix controller to communicate with and control up to 125 PROFIBUS slave devices.

Does this module support acyclic messaging?

Yes, the MVI69-PDPMV1 supports PROFIBUS DPV1, which includes both cyclic data exchange and acyclic messaging for device configuration and parameterization.
