Siemens 6AV6647-0AF11-3AX0 SIMATIC HMI KTP1000 Basic Color PN

Siemens 6AV6647-0AF11-3AX0 SIMATIC HMI KTP1000 Basic Color PN

Description

The Siemens 6AV6647-0AF11-3AX0 is a SIMATIC HMI KTP1000 Basic Color PN operator panel. As part of the Siemens Basic Panel series, this unit is designed for cost-effective operator control and...

24 la gente está viendo esto ahora mismo

Disponibilidad: Bajas existencias: quedan 8

SKU: 6AV6647-0AF11-3AX0
Proveedora: Siemens
tipo: HMI Operator Panel
Related Series:

Envíos y devoluciones

Entrega confiable a nivel mundial

  • Transportistas: Envíos a través de DHL, FedEx, UPS o USPS .
  • Envío: Los pedidos se procesan en 1-2 días hábiles y se envían dentro de 3-5 días hábiles .
  • Seguimiento: Detalles completos de seguimiento proporcionados por correo electrónico después del envío.

Garantía de devolución de dinero de 30 días

  • Garantía: período de devolución de 30 días para productos en stock y sellados de fábrica.
  • Condición: Los artículos deben estar sin abrir, sin usar y en su embalaje original.
  • Autenticidad: Garantizamos hardware 100% original y auténtico.

¿Necesitas más información? Consulta nuestra Política de envíos y reembolsos completa.

Autenticidad y garantía

  • Garantía genuina: Suministramos únicamente piezas de automatización industrial 100% originales, nuevas y selladas de fábrica .
  • Cobertura total: cada componente está respaldado por una garantía integral de 12 meses a partir de la fecha de compra.
  • Trazabilidad: Todos los productos se entregan con documentación original de fábrica y accesorios para un pleno cumplimiento industrial.

Soporte técnico y abastecimiento

  • Asistencia de expertos: Nuestro equipo técnico ofrece consulta gratuita para ayudarle a verificar la compatibilidad de los sistemas DCS y PLC.
  • Abastecimiento de piezas raras: nos especializamos en componentes obsoletos y difíciles de encontrar de Allen-Bradley, Siemens, ABB, HIMA y más.
  • Consultas al por mayor: contáctenos en pambo@5gplc.com para obtener precios por volumen o cotizaciones de proyectos personalizados.
Ver todos los detalles

Description

The Siemens 6AV6647-0AF11-3AX0 is a SIMATIC HMI KTP1000 Basic Color PN operator panel. As part of the Siemens Basic Panel series, this unit is designed for cost-effective operator control and monitoring of machines and industrial plants. It features a 10.4-inch TFT display with 256 colors and provides a dual-input interface combining a resistive touchscreen with tactile function keys. This model is equipped with a PROFINET interface, allowing for high-speed, Ethernet-based communication with SIMATIC controllers such as the S7-1200, S7-1500, S7-300, and S7-400 series.

Features

  • 10.4-inch TFT display with 640 x 480 pixel resolution.
  • Dual-mode operation: Resistive touch screen and 8 tactile function keys.
  • Integrated PROFINET interface for seamless integration into industrial Ethernet networks.
  • Supports configuration via WinCC flexible 2008 SP2 Compact, WinCC Basic V10.5, and STEP 7 Basic V10.5.
  • Robust design suitable for standard machine-level HMI applications.

Applications

  • General Manufacturing: Visualization for assembly lines and conveyor control.
  • Packaging Machinery: Monitoring of speed, temperature, and motion parameters.
  • Food & Beverage Processing: Recipe management and filling process control.
  • Process Automation: Auxiliary process monitoring, pump control, and tank level management.
  • Machine Building: Standardized HMI interface for custom industrial equipment.

Technical Specifications

Product Model 6AV6647-0AF11-3AX0
Display Type TFT
Screen Diagonal 10.4 in
Resolution 640 x 480 pixels
Color Depth 256 colors
MTBF Backlighting (at 25 degC) 50,000 h
Supply Voltage (DC) 24 V (19.2 V to 28.8 V)
Current Consumption 0.6 A
Active Power Input 15 W
Interface PROFINET
Weight 2.24 kg

Installation Guidelines

  • Mounting: Designed for horizontal mounting. Note that vertical mounting reduces the maximum allowable ambient temperature by 10 degC.
  • Panel Cutout: Prepare a precise cutout of 310 mm (width) x 248 mm (height).
  • Clearance: Maintain at least 50 mm of free space around all sides of the device to ensure adequate natural convection cooling.
  • Panel Thickness: Compatible with cabinet walls between 1.5 mm and 6.0 mm thick.
  • Sealing: Ensure the rubber seal is seated perfectly flat in the groove to maintain the IP65 front-face protection rating.
  • Clamping: Tighten mounting clamps evenly to a torque of 0.2 Nm. Avoid over-tightening to prevent damage to the plastic housing.

FAQ

What is the 6AV6647-0AF11-3AX0?

The Siemens SIMATIC HMI KTP1000 Basic Color is a 1st generation operator panel used for industrial automation and man-machine interaction.

What PLC types can it communicate with?

It is primarily used with S7-1200 and S7-1500 PLCs, but supports S7-300/400 series controllers over PROFINET.

What are the key display specifications?

The unit features a 10.4-inch TFT display with 256 colors and a resolution of 640 x 480 pixels. It features a resistive touchscreen complemented by 8 tactile function keys.

What are the power requirements?

It operates on 24 V DC electrical power, with a typical active power input of 15 W and a rated current consumption of 0.6 A.
