3500/22 164466-01 Bently Nevada Rack Interface Module

3500/22 164466-01 Bently Nevada Rack Interface Module

Product Description

The 3500/22 (164466-01) serves as the primary communication gateway for the Bently Nevada 3500 Monitoring System. It establishes a high-speed data link between the rack's internal backplane and external management...

28 people are viewing this right now

Availability: Low stock: 10 left

SKU: 3500/22 164466-01
Vendor: Bently Nevada
Category: Rack Interface Module
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

Product Description

The 3500/22 (164466-01) serves as the primary communication gateway for the Bently Nevada 3500 Monitoring System. It establishes a high-speed data link between the rack's internal backplane and external management software, such as System 1. This module is essential for capturing both high-resolution transient waveforms and steady-state vibration data, ensuring maintenance teams have access to actionable machinery diagnostics.

By utilizing the 3500/22, operators can configure rack parameters and monitor system health in real-time. The module supports robust Ethernet connectivity options, including fiber-optic interfaces for environments with high electromagnetic interference or long-distance transmission requirements.

Technical Specifications

Specification Details
Primary Identification Bently Nevada 3500/22 Enhanced RIM
Part Number 164466-01
Power Consumption 10.5 Watts (Nominal)
Network Interface (Front) 10Base-T or 100Base-TX Ethernet RJ-45 Port
Network Interface (I/O) 100Base-FX Fiber-Optic (SC Connectors)
Data Acquisition Supports Static Data, Direct Waveforms, and Transient Events (Startup/Coast-down)
Address Capacity Hardware-selectable rack addresses ranging from 1 to 127
Operating Modes Integrated Keylock for "Run" and "Program" security states

Indicator Matrix

  • OK LED: System self-test status

  • TX/RX LED: Active backplane and external communication traffic

  • TM LED: Verification of Trip Multiply mode activation

  • CONFIG OK LED: Validation of loaded rack configuration

Relay Logic

  • Dedicated "Not OK" contact for remote system health alerting

Application Scenarios

The 3500/22 (164466-01) is typically deployed in critical machinery protection environments, including:

  • Power Generation: Monitoring steam and gas turbine vibration and thrust

  • Oil & Gas: Interfacing centrifugal compressors with plant-wide DCS networks

  • Water Treatment: Remote diagnostics for large-scale pumping stations

Frequently Asked Questions

Does the 3500/22 support Transient Data Collection?
Yes. The 3500/22 is specifically designed to buffer and transmit high-speed transient data during machine startup or coast-down events for advanced phase and orbit analysis.

Is this module backward compatible with older 3500 racks?
The 3500/22 is compatible with standard 3500 rack backplanes, though it specifically interfaces with M-series monitors like the 3500/40M or 3500/42M for full data functionality.
