3500/61-01-05 Bently Nevada Temp Monitor with Barriers

3500/61-01-05 Bently Nevada Temp Monitor with Barriers

Product Description

The 3500/61-01-05 is a high-performance 6-channel temperature monitoring module part of the Bently Nevada 3500 Machinery Protection System. This specific configuration is distinguished by its integrated recorder outputs...

28 people are viewing this right now

Availability: Low stock: 10 left

SKU: 3500/61-01-05
Vendor: Bently Nevada
Category: Temp Monitor with Barriers
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

Product Description

The 3500/61-01-05 is a high-performance 6-channel temperature monitoring module part of the Bently Nevada 3500 Machinery Protection System. This specific configuration is distinguished by its integrated recorder outputs and Internal Safety Barriers, making it suitable for direct connection to sensors located in hazardous areas. It accepts both Resistance Temperature Detectors (RTDs) and Thermocouples (TCs), providing continuous surveillance of critical machinery temperatures in turbines, compressors, and large motors.

Technical Specifications

Specification Details
Channel Count 6 independent temperature monitoring channels
I/O Module Type (-01) RTD/TC Non-Isolated I/O Module with Internal Terminations (direct wiring to the rear of the rack)
Safety Option (-05) Integrated Internal Barriers for intrinsically safe field wiring
Input Types * RTDs: 100Ω Platinum (alpha 0.00385/0.00392), 120Ω Nickel, and 10Ω Copper
* Thermocouples: Type E, J, K, T, and S
Recorder Outputs Independent +4 to +20 mA DC proportional output for each of the 6 channels
Isolation 500 Vdc system isolation; non-isolated channel-to-channel
Power Consumption 9.0 Watts nominal
Dimensions 241.3 mm x 24.4 mm x 241.8 mm (Monitor)
Weight 0.91 kg
Operating Temperature 0°C to +65°C

System Integration

The 3500/61 differs from the standard 3500/60 by providing 4-20 mA recorder outputs for every channel, allowing for seamless integration with a DCS or PLC for trending and secondary control. The -05 internal barrier option simplifies installation in hazardous environments by eliminating the need for bulky external safety barriers, significantly reducing cabinet space requirements and wiring complexity.

Engineering FAQ

Q: Does the 3500/61-01-05 require a separate terminal block?
A: No. Because this version uses Internal Terminations, field wires are connected directly to the compression screw terminals on the back of the I/O module.
