Configured for discrete signal interfacing and field contact monitoring in MicroNet control platforms, the Woodward 5466-1050 (5466-1050 Discrete I/O Module) provides direct physical/electrical execution.

Hardware Specifications

...
18 people are viewing this right now

Availability: Low stock: 6 left

SKU: 5466-1050
Vendor: Woodward
Category: MicroNet Simplex Discrete I/O Module
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

Configured for discrete signal interfacing and field contact monitoring in MicroNet control platforms, the Woodward 5466-1050 (5466-1050 Discrete I/O Module) provides direct physical/electrical execution.

Hardware Specifications

Parameter Specification
Model 5466-1050
Brand Woodward
Origin USA
Weight 2.16 kg
Dimensions 22.2 cm x 8 cm x 26.6 cm
Operating Temp Standard Industrial Range (0 to +55 deg C)
Power Consumption Standard Backplane Load
Series MicroNet Series
Discrete Inputs 48 channels
Discrete Outputs 24 channels
Configuration Architecture Simplex

Thermal Heat Sink Dissipation & Actuator Loop Feedback

Internal backplane power conversion and contact driver circuits generate operational heat managed through convection cooling across the card profile. Maintaining effective thermal heat sink dissipation prevents local thermal buildup inside the MicroNet chassis during high simultaneous I/O channel activation. Fast input optocoupler scanning and precise discrete output switching provide deterministic field actuation, preserving tight actuator loop feedback response times during sequence-of-events processing.

Frequently Asked Questions

  • Q: What wiring precautions should be observed for discrete input field channels?
  • A: Field contact sensing lines must use shielded wiring routed separately from high-voltage AC power conductors to prevent false contact state triggering from electromagnetic noise.
  • Q: How is ground isolation managed between field wiring and backplane electronics?
  • A: Discrete inputs and outputs feature optical and galvanic isolation barriers separating field-side DC power sources from the internal MicroNet system backplane bus.
  • Q: What cooling clearance is required when installing this module into a MicroNet chassis?
  • A: Unobstructed vertical airflow through the chassis fan assembly must be maintained to ensure uniform air velocity across the card components.

Field Installation Guidelines

  • Insert the card firmly into the designated MicroNet chassis slot, ensuring backplane connectors align fully before tightening retaining screws.
  • Connect shield drain wires to the designated chassis grounding rail to maintain noise immunity across all 48 input and 24 output channels.
  • Ensure field contact power supplies incorporate appropriately rated inline protection fuses prior to wiring input groups.
  • Verify field wiring polarity against channel terminal assignments before supplying power to external contact loops.
