5466-258 Woodward Discrete I/O Module

5466-258 Woodward Discrete I/O Module

Technical Overview

The 5466-258 is a high-density discrete I/O module for Woodward MicroNet and MicroNet Plus control systems. This Simplex module serves as a critical interface for turbine and industrial engine control, monitoring field switches and commanding discrete...

28 people are viewing this right now

Availability: Low stock: 10 left

SKU: 5466-258
Vendor: Woodward
Category: Discrete I/O Module
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

Technical Overview

The 5466-258 is a high-density discrete I/O module for Woodward MicroNet and MicroNet Plus control systems. This Simplex module serves as a critical interface for turbine and industrial engine control, monitoring field switches and commanding discrete actuators.

Integrated into the MicroNet VME backplane, it delivers sub-millisecond deterministic performance for high-speed digital state processing.

Technical Specifications

Specification Details
Part Number 5466-258
Model Series MicroNet / MicroNet Plus
Module Type Simplex Discrete I/O
Input Channels 48 Discrete Inputs (24 Vdc)
Output Channels 24 Discrete Outputs (High-side switches)
Input Voltage Range 18–32 Vdc
Output Current Rating 500 mA per channel (continuous)
Communication Interface VMEbus compliant
Physical Dimensions 2.4 × 24.6 × 26.1 cm
Net Weight 0.86 kg

Operational Logic and System Utility

The 5466-258 handles the strict timing requirements of power generation and mechanical drive systems.

  • Inputs: 48 discrete points for limit switches, pressure switches, and operator commands.

  • Outputs: 24 channels to drive relays or solenoid valves.

As a Simplex module, it provides a cost-effective non-redundant control path while maintaining high reliability and diagnostic coverage consistent with the Woodward MicroNet family.

Frequently Asked Questions

Q: What is the difference between the 5466-258 and a redundant TMR module?
A: The 5466-258 is Simplex, operating as a single I/O path. TMR modules use three redundant paths with voting logic for higher fault tolerance in mission-critical safety functions.

Q: Does the 5466-258 require a separate FTM (Field Terminal Module)?
A: Yes, it typically connects to a Woodward FTM via high-density molded cable for organized field wiring and additional circuit protection.
