Siemens 560-2136 Global Memory Card for TI 560/565 Series

Siemens 560-2136 Global Memory Card for TI 560/565 Series

Description

The Siemens 560-2136 is a Global Memory Card designed for use with the Siemens TI 560 and TI 565 programmable logic controller (PLC) systems. This memory module provides 256 words...

28 people are viewing this right now

Availability: Low stock: 6 left

SKU: 560-2136
Vendor: Siemens
Category: PLC Memory Module
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

Description

The Siemens 560-2136 is a Global Memory Card designed for use with the Siemens TI 560 and TI 565 programmable logic controller (PLC) systems. This memory module provides 256 words of global memory, serving as a critical component for expanding the data storage and operational capacity of the legacy TI 500 series control architecture.

Features

  • Compatible with Siemens TI 560 and TI 565 PLC platforms.
  • Provides 256 words of global memory for program and data management.
  • Robust construction designed for industrial rack-mounted environments.
  • Directly interfaces with the PLC backplane for high-speed data access.

Applications

This memory card is primarily used in legacy industrial automation systems where TI 560/565 controllers are deployed. It is essential for applications requiring additional global memory for complex logic, data logging, or inter-processor communication within the TI 500 series environment.

Technical Specifications

Product Model 560-2136
Manufacturer Siemens
Memory Capacity 256 Words
Component Type Global Memory Card
System Compatibility TI 560 / TI 565

Installation Guidelines

  • Ensure the PLC system is powered down before inserting or removing the memory card to prevent electrical damage or data corruption.
  • Handle the module by its edges; avoid touching the gold-plated edge connectors to prevent oxidation or contamination.
  • Ensure the card is fully seated in the designated slot of the PLC rack to maintain reliable electrical contact.
  • Maintain a clean, dry, and vibration-free environment to ensure the longevity of the module and the host controller.
  • Follow standard ESD (Electrostatic Discharge) precautions when handling the module to protect sensitive internal components.

FAQ

What is the primary function of the 560-2136?

The 560-2136 acts as a global memory expansion module, providing 256 words of additional storage for the Siemens TI 560 and 565 PLC systems.

Is this module compatible with other TI series controllers?

This module is specifically engineered for the TI 560/565 series. Compatibility with other TI series controllers should be verified against the specific hardware manual for that controller model.
