Siemens 6ES5466-3LA11 SIMATIC S5 Analog Input Module

Siemens 6ES5466-3LA11 SIMATIC S5 Analog Input Module

The Siemens 6ES5466-3LA11 is a floating (galvanically isolated) analog input module designed for integration within the SIMATIC S5 automation family. It is compatible with S5-115U/H/F, S5-135U, and S5-155U/H PLC systems,...

29 people are viewing this right now

Availability: Low stock: 5 left

SKU: 6ES5466-3LA11
Vendor: Siemens
Category: Analog Input Module
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

The Siemens 6ES5466-3LA11 is a floating (galvanically isolated) analog input module designed for integration within the SIMATIC S5 automation family. It is compatible with S5-115U/H/F, S5-135U, and S5-155U/H PLC systems, providing reliable signal acquisition for industrial process control.

Features

  • Compatible with S5-115U/H/F, S5-135U, and S5-155U/H PLC series.
  • Configurable for 16 single-ended or 8 differential analog input channels.
  • Floating design ensures galvanic isolation between input circuits and the PLC internal bus.
  • Supports a wide range of voltage and current input signals.
  • Designed for integration in electrically noisy industrial environments.

Applications

  • Process variable monitoring (temperature, pressure, flow, and level).
  • Motion and position control systems.
  • Industrial infrastructure, including water treatment and oil and gas facilities.
  • Logic control in automated production lines.

Technical Specifications

Model 6ES5466-3LA11
Input Channels 16 (single-ended) or 8 (differential)
Input Impedance (Voltage) > 10 MΩ
Input Impedance (Current) 125 Ω
Internal Supply Voltage +5 V (+/- 5%)
Internal Current Consumption Typically 0.6 A
Power Loss 3 W
Rated Isolation Voltage 500 V (channels to ground)
Supported Input Ranges 0-20 mA, 4-20 mA, +/- 20 mA, 0-1.25 V, 0-2.5 V, 0-5 V, 1-5 V, 0-10 V, +/- 1.25 V, +/- 2.5 V, +/- 5 V, +/- 10 V

Installation Guidelines

  • Ensure the PLC system is powered down before inserting or removing the module from the rack.
  • Use shielded twisted-pair cabling for all analog signal connections to minimize EMI/RFI interference.
  • The module does not provide power to 2-wire transducers; ensure an external power supply is used in series with the loop.
  • Maintain proper grounding practices to ensure the integrity of the floating isolation barrier.
  • Ensure adequate ventilation in the cabinet to dissipate the 3 W typical power loss.

FAQ

What is the 6ES5466-3LA11 module?

The 6ES5466-3LA11 is an analog input module used in S5-115U/H/F, S5-135U, and S5-155U/H PLC systems to acquire field analog voltage or current signals.

How many analog inputs does the 6ES5466-3LA11 have?

The module supports 16 single-ended analog input channels or 8 differential analog input channels, depending on the configuration.

What is the input impedance of the 6ES5466-3LA11 module?

For voltage inputs, the input impedance is greater than 10 MΩ; for current inputs, the input loop resistance is 125 Ω.
