Siemens 6ES5470-4UA13 Simatic S5 Analog Output Module

Siemens 6ES5470-4UA13 Simatic S5 Analog Output Module

Description

The Siemens Simatic S5 6ES5470-4UA13 is an 8-channel isolated analog output module designed for integration within the Simatic S5-135U and S5-155U programmable controller systems. This module serves as a critical...

19 people are viewing this right now

Availability: Low stock: 2 left

SKU: 6ES5470-4UA13
Vendor: Siemens
Category: Analog Output Module
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

Description

The Siemens Simatic S5 6ES5470-4UA13 is an 8-channel isolated analog output module designed for integration within the Simatic S5-135U and S5-155U programmable controller systems. This module serves as a critical interface between the digital processor and field-level analog devices, converting internal binary data into precise voltage or current signals required for modulating actuators, proportional valves, and frequency converters in industrial environments.

Features

  • 8-point isolated analog output configuration.
  • Galvanic isolation for each channel to mitigate ground loops and signal interference.
  • High-precision digital-to-analog conversion with minimal thermal drift.
  • Integrated diagnostic reporting to the CPU for rapid fault detection.
  • Robust mechanical design for operation in demanding industrial process environments.

Applications

This module is widely deployed in continuous process automation, including power generation, oil and gas, and heavy manufacturing. It is specifically suited for applications requiring stable, high-density analog control loops where signal integrity and electrical isolation from the controller backplane are essential.

Technical Specifications

Model 6ES5470-4UA13
Product Family Simatic S5-135U / S5-155U
Module Type Analog Output Module
Channel Count 8 Channels (Floating)
Power Consumption 3.6 W
Operating Temperature 0 to 60 deg C

Installation Guidelines

  • Ensure the controller chassis power is disconnected before inserting or removing the module.
  • Verify that the module is correctly seated in the rack slot to ensure proper backplane contact.
  • Use shielded cabling for all analog output connections to minimize electromagnetic interference (EMI).
  • Maintain proper spacing from high-voltage power lines and high-frequency noise sources.
  • Ensure adequate ventilation within the cabinet to maintain the operating temperature within the specified 0 to 60 deg C range.

FAQ

Is this module compatible with all Simatic S5 systems?

The 6ES5470-4UA13 is specifically engineered for the S5-135U and S5-155U controller chassis. Please verify your specific CPU and rack configuration before installation.

Does this module require external power for the outputs?

Yes, as an analog output module, it requires appropriate loop power to drive field devices. Refer to the specific technical manual for the S5-135U/155U series for wiring diagrams and voltage requirements.
