Siemens 6ES7195-7HD10-0XA0 SIMATIC DP Bus Module for ET 200M Redundancy

Siemens 6ES7195-7HD10-0XA0 SIMATIC DP Bus Module for ET 200M Redundancy

Description

The Siemens 6ES7195-7HD10-0XA0 is a specialized bus module designed for the SIMATIC DP ET 200M distributed I/O system. This unit is engineered to support redundant configurations, specifically designed to hold...

16 people are viewing this right now

Availability: Low stock: 6 left

SKU: 6ES7195-7HD10-0XA0
Vendor: Siemens
Category: Bus Module
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

Description

The Siemens 6ES7195-7HD10-0XA0 is a specialized bus module designed for the SIMATIC DP ET 200M distributed I/O system. This unit is engineered to support redundant configurations, specifically designed to hold two IM 153-2 interface modules. It facilitates high-availability system architectures by allowing for the removal and insertion of modules during active operation (Hot Swapping) without interrupting the process cycle.

Features

  • Supports redundant IM 153-2 interface module configurations.
  • Enables hot-swapping (removal and insertion) of modules during RUN mode.
  • Optimized for integration within the SIMATIC ET 200M distributed I/O platform.
  • Robust design for industrial environmental conditions.

Technical Specifications

Product Model 6ES7195-7HD10-0XA0
Function Bus Unit for Redundancy
Operating Temperature -25 degC to +60 degC
Storage/Transport Temperature -40 degC to +70 degC
Relative Humidity 5% to 95% (non-condensing)
Tariff Code 8537101190

Installation Guidelines

  • Ensure the power is disconnected from the rack before installing or removing the bus module to prevent electrical damage.
  • Mount the module securely onto the standard DIN rail as per the ET 200M system layout requirements.
  • Verify that the interface modules (IM 153-2) are correctly seated and locked into the bus unit to ensure reliable communication.
  • Maintain proper ventilation clearance around the ET 200M station to ensure operating temperatures remain within the specified -25 degC to +60 degC range.
  • Handle with care to avoid electrostatic discharge (ESD) damage to the backplane connectors.

FAQ

What is the primary purpose of the 6ES7195-7HD10-0XA0?

This bus unit is used in SIMATIC ET 200M systems to enable redundant operation by housing two IM 153-2 interface modules, ensuring system availability even if one interface fails.

Does this module support hot-swapping?

Yes, this bus unit supports the removal and insertion of modules while the system is in RUN mode, provided the overall system configuration supports this functionality.
