Siemens 6FM1726-3CA10 Simatic S5 Positioning Module

Siemens 6FM1726-3CA10 Simatic S5 Positioning Module

Description

The Siemens 6FM1726-3CA10 is a specialized positioning module engineered for the Simatic S5-135 and S5-155 PLC systems. Identified as the WF726C (Version 1.7), this module provides robust motion control capabilities,...

20 people are viewing this right now

Availability: Low stock: 9 left

SKU: 6FM1726-3CA10
Vendor: Siemens
Category: Positioning Module
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

Description

The Siemens 6FM1726-3CA10 is a specialized positioning module engineered for the Simatic S5-135 and S5-155 PLC systems. Identified as the WF726C (Version 1.7), this module provides robust motion control capabilities, facilitating precise axis positioning for industrial machinery. By offloading complex motion algorithms and position calculations from the main CPU to the module hardware, it ensures deterministic performance and high-speed feedback processing in demanding environments such as steel processing, conveyor systems, and heavy manufacturing.

Features

  • Supports both serial-absolute (SSI) and incremental encoder interfaces.
  • Executes high-speed motion control without jerk limitation.
  • Reduces CPU load by processing position calculations locally on the module.
  • Designed for integration into the S5-135 and S5-155 backplane architecture.
  • Ensures reliable signal integrity for closed-loop motion feedback.

Applications

This module is primarily utilized in legacy Simatic S5 automation systems requiring high-precision axis control. Typical applications include automated rolling mills, paper processing lines, and material handling conveyors where accurate synchronization and tracking are critical to operational safety and output quality.

Technical Specifications

Model 6FM1726-3CA10 (WF726C V 1.7)
System Compatibility Siemens Simatic S5-135/155
Encoder Support Serial-absolute (SSI) and incremental square-wave
Operating Temperature 0 to 55 deg C
Power Supply 5 VDC (backplane) and 24 VDC (external encoder supply)

Installation Guidelines

  • Ensure the PLC rack is powered down before inserting or removing the module to prevent electrical damage.
  • Verify that the module is correctly seated in the S5 backplane to maintain rigid signal integrity.
  • Use shielded cabling for encoder connections to minimize EMI interference in high-vibration environments.
  • Maintain adequate ventilation within the control cabinet to ensure the module operates within the specified 0-55 deg C range.
  • Handle with standard ESD precautions to protect internal circuitry during installation.

FAQ

What is the primary function of the 6FM1726-3CA10?
It acts as a dedicated positioning controller for the Simatic S5-135/155 series, managing motion control tasks and encoder feedback to improve system accuracy and reduce CPU overhead.

Does this module support SSI encoders?
Yes, the WF726C supports point-to-point interfacing with absolute encoders via Synchronous Serial Interface (SSI) in addition to standard incremental signals.
