The A6312-8 is a high-performance dual-channel speed acquisition and phase reference module designed for the Emerson AMS 6500 Machinery Protection System. This module captures critical rotational data from high-speed turbomachinery, providing precise timing...
Availability: Low stock: 99 left
Reliable Worldwide Delivery
30-Day Money-Back Guarantee
Need more details? Read our fullShipping PolicyandRefund Policy.
The A6312-8 is a high-performance dual-channel speed acquisition and phase reference module designed for the Emerson AMS 6500 Machinery Protection System. This module captures critical rotational data from high-speed turbomachinery, providing precise timing pulses necessary for synchronous vibration analysis. By processing inputs from two independent sensors, the A6312-8 enables engineers to monitor shaft RPM and establish a Phase Reference (Keyphasor) for advanced diagnostics like orbit and polar plots.
Built for industrial and power generation environments, the A6312-8 ensures deterministic, drift-free measurements, making it ideal for detecting overspeed conditions and providing a "Once-Per-Turn" trigger for machinery health monitoring. Integrated into the AMS 6500 rack, the module supports both backplane communication for DCS integration and front-panel buffered outputs for real-time field analysis.
| Specification | Details |
|---|---|
| Model Number | A6312-8 (A6312/08) |
| Monitoring Capability | Dual-Channel (2 independent speed/phase inputs) |
| Input Frequency Range | 0.01 Hz to 50,000 Hz |
| Signal Compatibility | Eddy current probes, Hall-effect sensors, Magnetic Pickups (MPU) |
| Output Interface | Dual Buffered BNC outputs (front-panel) |
| Backplane Communication | For system-wide protection logic |
| Diagnostic Logic | Continuous monitoring of sensor health and signal continuity |
| Resolution | Precision interval timing for high-accuracy RPM calculation |
| Operational Temperature | -20°C to +65°C (-4°F to +149°F) |
| Dimensions | 24.0 cm x 17.0 cm x 6.5 cm |
| Weight | 0.38 kg |
The A6312-8 is essential in utility-scale power plants for monitoring steam and gas turbine shafts. It is also widely used in the petrochemical industry for centrifugal compressor trains, where accurate phase reference data is necessary to detect issues such as rotor unbalance, shaft misalignment, or bearing degradation using synchronous vibration vectoring.
Can the A6312-8 monitor two different shafts simultaneously?
Yes, the A6312-8 features two independent channels. You can configure one for Speed Input and the other as a Phase Reference (Key), or use both for redundant speed monitoring of the same shaft.
Is this module compatible with older MMS 6000 racks?
Yes, the A6312-8 is backward compatible with the MMS 6000 platform, allowing it to be used as a drop-in replacement or for system expansion in legacy installations.
How are the trigger thresholds adjusted for different sensors?
Thresholds and hysteresis are software-configurable via the AMS 6500 configuration utility, allowing the module to adapt to varying signal amplitudes from passive or active sensors.
