ABB 3BHE012551R0001 UAD142 A HVDC Power Module

ABB 3BHE012551R0001 UAD142 A HVDC Power Module

Description

The ABB 3BHE012551R0001 (UAD142 A) is a specialized HVDC power module engineered for high-voltage direct current transmission applications. This module is designed to manage significant power loads in demanding industrial...

23 people are viewing this right now

Availability: In stock

SKU: 3BHE012551R0001 3BHE012552P201 UAD142 A
Vendor: ABB
Category: HVDC Power Module
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

Description

The ABB 3BHE012551R0001 (UAD142 A) is a specialized HVDC power module engineered for high-voltage direct current transmission applications. This module is designed to manage significant power loads in demanding industrial environments, providing reliable performance in critical energy infrastructure.

Features

  • Robust design for high-voltage power conversion
  • Designed for integration into HVDC systems
  • Supports high nominal DC voltage and current ratings
  • Optimized for thermal efficiency under heavy load conditions

Applications

This power module is specifically utilized in HVDC (High Voltage Direct Current) transmission systems, supporting power conversion and distribution infrastructure where high-capacity electrical management is required.

Technical Specifications

Product Model 3BHE012551R0001 / 3BHE012552P201 / UAD142 A
Nominal DC Voltage 4,200 V DC
Application Voltage +/- 525 kV
Rated DC Current 4,500 A
Peak Non-Repetitive Current 6,000 A (for 1 s)
Power Dissipation 28 kW @ 4 kA
Control Power 24 V DC
Operating Temperature -40 to +45 degC (ambient oil)
Storage Temperature -50 to +85 degC
Humidity <= 95% RH

Installation Guidelines

  • Ensure the module is installed in an environment compliant with the specified ambient oil temperature range.
  • Handle with care to prevent damage to sensitive power electronics.
  • Verify that all electrical connections are secured and rated for the intended high-voltage and high-current operation.
  • Ensure proper grounding and isolation protocols are followed according to the specific HVDC system documentation.
  • Maintain adequate ventilation or cooling systems to manage the power dissipation of 28 kW during operation.

FAQ

What is the primary application for the UAD142 A module?
This module is designed for HVDC power systems, specifically for high-voltage transmission and conversion applications.

What is the rated DC current for this unit?
The module is rated for a nominal DC current of 4,500 A, with a peak non-repetitive current capacity of 6,000 A for 1 second.
