ABB NPCT-01C 64009486 Pulse Counter/Timer Unit

ABB NPCT-01C 64009486 Pulse Counter/Timer Unit

The ABB NPCT-01C (Order Code: 64009486) is a specialized pulse counter and timer module designed for integration within the ACS 800 drive series ecosystem. This unit provides precise pulse counting...

15 people are viewing this right now

Availability: Low stock: 5 left

SKU: NPCT-01C 64009486
Vendor: ABB
Category: Pulse Counter Module
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

The ABB NPCT-01C (Order Code: 64009486) is a specialized pulse counter and timer module designed for integration within the ACS 800 drive series ecosystem. This unit provides precise pulse counting and timing functionality, essential for applications requiring accurate synchronization, speed monitoring, or event tracking in industrial automation environments.

Features

  • Integrated pulse counting and timing capabilities for high-precision control.
  • Designed for compatibility with ABB ACS 800 drive systems.
  • Robust electrical isolation rated at 1500 V AC to protect internal circuitry from transient surges.
  • Wide operating temperature range suitable for demanding industrial environments.

Technical Specifications

Product Model NPCT-01C
Order Code 64009486
Spare Model 64009486D
Input Voltage 24 V DC nominal
Power Supply 5 V DC
Power Consumption 2-4 W
Isolation 1500 V AC
Operating Temperature -20 degC to +70 degC
Storage Temperature -40 degC to +85 degC
Humidity 5-95% RH (non-condensing)

Installation Guidelines

  • Ensure the drive system is fully powered down and locked out before attempting to install or remove the NPCT-01C module.
  • Handle the module using proper ESD (Electrostatic Discharge) safety protocols to prevent damage to internal components.
  • Ensure the module is securely seated in the designated slot to maintain proper electrical contact and mechanical stability.
  • Verify that all input wiring is routed away from high-voltage power cables to minimize electromagnetic interference (EMI).
  • Confirm that the 24 V DC supply is within the specified nominal range before energizing the system.

FAQ

What is the primary function of the NPCT-01C?

The NPCT-01C is a pulse counter and timer unit used to track pulses or time intervals within an ABB ACS 800 drive configuration, facilitating precise process control.

Is this module compatible with other ABB drive series?

The NPCT-01C is specifically designed for the ACS 800 series. Please consult your drive's hardware manual or technical documentation to confirm compatibility with your specific drive model and firmware version.

What should I do if the module is not registering pulses?

First, verify the 24 V DC input wiring and ensure the signal source is functioning correctly. Check the drive's diagnostic parameters to see if the module is recognized by the system and if there are any active fault codes related to the I/O configuration.
