ABB PS861E High Performance I/O DSP Board 1JNL100114-077

ABB PS861E High Performance I/O DSP Board 1JNL100114-077

Description

The ABB PS861E is a high-performance I/O DSP (Digital Signal Processor) board designed for demanding industrial automation environments. As part of the Advant AC800M ecosystem, this module provides advanced processing...

23 people are viewing this right now

Availability: Low stock: 2 left

SKU: PS861E
Vendor: ABB
Category: I/O Processor Module
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

Description

The ABB PS861E is a high-performance I/O DSP (Digital Signal Processor) board designed for demanding industrial automation environments. As part of the Advant AC800M ecosystem, this module provides advanced processing capabilities for complex signal handling and I/O management. It is engineered for high-speed data acquisition and real-time control, ensuring reliable performance in critical automation tasks.

Features

  • Advanced 32-/64-bit floating-point CPU architecture for high-speed signal processing.
  • Integrated 32 MB Flash memory for robust data and firmware storage.
  • High-density I/O configuration: 48 simultaneous 16-bit analog inputs, 64 digital inputs, and 32 digital outputs.
  • Wide operating temperature range from -25 degC to +70 degC without derating.
  • Low power dissipation of 18 W at 225 MHz.
  • Designed for high-reliability industrial applications with a 10 ms hold-up time.

Technical Specifications

Model PS861E
Part Number 1JNL100114-077
CPU 32-/64-bit floating-point
Flash Memory 32 MB
Analog Inputs 48 x 16-bit simultaneous
Digital Inputs 64 x 24 V DC
Digital Outputs 32 x 24 V DC
Logic Supply 5 V DC +/- 3%
Field Bias +/- 15 V DC
Power Dissipation 18 W @ 225 MHz, 25 degC
Operating Temperature -25 to +70 degC
Storage Temperature -40 to +85 degC
Humidity 5 to 95% RH (non-condensing)

Installation Guidelines

  • Ensure the system power is completely disconnected before installing or removing the PS861E module from the rack.
  • Handle the module using proper ESD (Electrostatic Discharge) precautions to prevent damage to internal circuitry.
  • Verify that the backplane connection is secure and that the module is correctly seated in the designated slot.
  • Ensure adequate ventilation in the cabinet to maintain operating temperatures within the specified range.
  • Route signal and power cables separately to minimize electromagnetic interference (EMI).
  • Check that the logic supply voltage (5 V DC) is stable and within the +/- 3% tolerance before energizing the system.

FAQ

What is the primary function of the PS861E?

The PS861E is a high-performance I/O DSP board used for processing analog and digital signals within the ABB Advant AC800M control system, providing high-speed computational power for I/O management.

Can this module operate in extreme temperatures?

Yes, the module is rated for operation between -25 degC and +70 degC without the need for power derating, making it suitable for harsh industrial environments.
