ABB DSDP150 Advant S100 Pulse Counting and Positioning Module

ABB DSDP150 Advant S100 Pulse Counting and Positioning Module

Description

The ABB DSDP150 is a specialized I/O module designed for the Advant S100 I/O system, primarily utilized for pulse counting and positioning applications. This module serves as an interface for...

25 people are viewing this right now

Availability: Low stock: 2 left

SKU: DSDP150
Vendor: ABB
Category: Pulse Counting and Positioning Module
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

Description

The ABB DSDP150 is a specialized I/O module designed for the Advant S100 I/O system, primarily utilized for pulse counting and positioning applications. This module serves as an interface for high-speed pulse encoders, allowing the control system to track position, speed, or count data with high precision. Although this unit is discontinued by the manufacturer, it remains a critical component for maintaining legacy Advant S100 control architectures.

Features

  • Designed for integration with the Advant S100 I/O bus.
  • Supports high-speed pulse encoder input processing.
  • Enables precise positioning and counting control loops.
  • Robust industrial design for standard control cabinet mounting.
  • Compatible with legacy ABB Advant controller environments.

Applications

The DSDP150 is typically deployed in industrial automation environments requiring motion feedback or high-frequency pulse monitoring. Common applications include conveyor speed monitoring, rotary encoder feedback for positioning systems, and flow meter pulse totalization within process control loops.

Technical Specifications

Manufacturer ABB
Model DSDP150
Spare Part Number 57160001-GF
Function Pulse Counting and Positioning
System Compatibility Advant S100 I/O
Weight 0.38 kg
Tariff Code 8538907080

Installation Guidelines

  • Ensure the Advant S100 rack is powered down before inserting or removing the DSDP150 module to prevent electrical damage.
  • Verify that the module is properly seated in the designated slot to ensure reliable backplane communication.
  • Use shielded cabling for pulse encoder inputs to minimize electromagnetic interference (EMI) and signal noise.
  • Maintain proper grounding practices for the control cabinet to protect sensitive input circuitry.
  • Ensure adequate ventilation within the cabinet to maintain operating temperatures within the specified range for electronic modules.

FAQ

Is the DSDP150 still supported by ABB?

The DSDP150 has been discontinued by the manufacturer. Support is generally limited to legacy system maintenance and the use of refurbished or surplus inventory.

What is the primary function of the DSDP150?

This module is an I/O interface specifically engineered to process pulse signals from encoders, facilitating accurate counting and positioning tasks within the Advant S100 system.
