ABB TU890 3BSC690075R1 Compact Module Termination Unit (MTU)

ABB TU890 3BSC690075R1 Compact Module Termination Unit (MTU)

Description

The ABB TU890 (3BSC690075R1) is a compact Module Termination Unit (MTU) specifically designed for the S800 I/O system. This passive unit serves as the primary interface for connecting field wiring...

15 people are viewing this right now

Availability: Low stock: 8 left

SKU: TU890 3BSC690075R1
Vendor: ABB
Category: Module Termination Unit
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

Description

The ABB TU890 (3BSC690075R1) is a compact Module Termination Unit (MTU) specifically designed for the S800 I/O system. This passive unit serves as the primary interface for connecting field wiring and process power to I/O modules. It also facilitates the distribution of the ModuleBus to the I/O module and subsequent MTUs, while managing correct addressing through the shifting of outgoing position signals.

Features

  • Compact footprint designed for space-efficient S800 I/O installations.
  • Integrated ModuleBus distribution for seamless communication between modules.
  • Mechanical keying mechanism to prevent the insertion of incorrect I/O modules.
  • Secure latching device for stable DIN rail mounting.
  • Supports field signal and process power connections via 27 terminals.
  • Compatible with a wide range of S800 I/O modules, including AI890, AI893, AI895, AO890, AO895, DI890, and DO890.

Applications

The TU890 is widely utilized in industrial environments requiring high-density, reliable I/O termination, particularly in sectors such as:

  • Oil and Gas: Offshore platforms, wellhead collection stations, and storage facilities.
  • Chemical Processing: Hydrogenation units, flammable solvent storage, and chemical delivery pump stations.
  • Logistics and Safety: Power and safety interlock monitoring for hazardous liquid chemicals.
  • Coal Chemical Industry: Gasification islands and coking workshops.

Technical Specifications

Model TU890
Order Code 3BSC690075R1
Manufacturer ABB
Type Compact MTU
Max Rated Voltage 50 V
Nominal Voltage 24 V
Max Current per Channel 2 A
Process Connections 27 Terminals
Mounting DIN Rail (Horizontal)
Country of Origin Sweden

Installation Guidelines

  • Mounting: Ensure the unit is securely latched onto a standard DIN rail. The design supports horizontal mounting configurations.
  • Safety: Always power down the system before inserting or removing I/O modules from the MTU to prevent electrical arcing or damage to the ModuleBus.
  • Handling: Use proper ESD (Electrostatic Discharge) precautions when handling the MTU to protect internal components.
  • Wiring: Ensure all field wiring is properly terminated to the designated terminals. Verify that the mechanical keying matches the intended I/O module before installation.
  • Environment: Maintain the installation within the specified ambient temperature limits (up to 55 degC) to ensure long-term operational reliability.

FAQs

What is the ABB TU890?

The TU890 is a compact Module Termination Unit (MTU) designed for the ABB S800 I/O system, used to connect field wiring and power supply to I/O modules.

What type of terminal connection does it use?

It features 27 terminals for process connections (field signals) and acts as a critical component in compact S800 I/O system architectures.

What is the voltage rating?

The nominal voltage is 24 V DC, with a maximum rated voltage of 50 V.
