ABB BDPS-11C 3AXD50000000051 Braking Chopper Board

ABB BDPS-11C 3AXD50000000051 Braking Chopper Board

Description

The ABB BDPS-11C (3AXD50000000051) is a specialized braking chopper board designed for integration into high-performance industrial drive systems. This component is engineered to manage excess energy generated during motor deceleration,...

28 people are viewing this right now

Availability: Low stock: 7 left

SKU: BDPS-11C 3AXD50000000051
Vendor: ABB
Category: Braking Chopper Board
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

Description

The ABB BDPS-11C (3AXD50000000051) is a specialized braking chopper board designed for integration into high-performance industrial drive systems. This component is engineered to manage excess energy generated during motor deceleration, converting it into heat via external braking resistors to prevent overvoltage in the DC link.

Features

  • Designed for high-capacity braking applications.
  • Supports DC link voltages ranging from 1000 V to 1200 V.
  • Capable of handling braking power between 250 kW and 1000 kW.
  • Robust construction for reliable operation in industrial environments.
  • Compatible with standard ABB drive system architectures.

Technical Specifications

Model BDPS-11C
Order Code 3AXD50000000051
Input Voltage (DC) 1000 to 1200 V DC link
Max. Braking Power 250 to 1000 kW
Operating Temperature -15 degC to +45 degC
Tariff Code 8537101190

Installation Guidelines

  • Ensure the drive system is fully powered down and the DC link capacitors are discharged before attempting to install or replace the BDPS-11C board.
  • Verify that the board is securely seated in the designated slot within the drive cabinet.
  • Maintain proper clearance around the braking chopper system to ensure adequate airflow and cooling.
  • Use appropriate ESD protection when handling the board to prevent damage to sensitive electronic components.
  • Ensure all electrical connections are tightened to the manufacturer's specified torque requirements to prevent arcing or poor contact.

Compliance and Certifications

The BDPS-11C is designed to meet international standards for industrial equipment, including CE, UL, and IEC 61800-5-1 compliance.

FAQ

What is the primary function of the BDPS-11C?
The BDPS-11C acts as a braking chopper, which is essential for dissipating regenerative energy in motor drive applications, ensuring the stability of the DC bus voltage.

What is the operating temperature range for this module?
This module is rated for operation in environments ranging from -15 degC to +45 degC.
