ABB DSTD110A 57160001-TZ Digital Output Card

ABB DSTD110A 57160001-TZ Digital Output Card

Description

The ABB DSTD110A (57160001-TZ) is a digital output connection unit designed for use within the ABB Master control system architecture. This module serves as a high-density interface for digital output...

23 people are viewing this right now

Availability: Low stock: 3 left

SKU: DSTD110A 57160001-TZ
Vendor: ABB
Category: Digital Output Module
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

Description

The ABB DSTD110A (57160001-TZ) is a digital output connection unit designed for use within the ABB Master control system architecture. This module serves as a high-density interface for digital output signals, providing robust signal distribution and termination for industrial automation applications.

Features

  • 32-channel digital output capacity for high-density control requirements.
  • Supports a maximum output voltage of 60 V DC per channel.
  • Robust current handling with a capacity of 3 A per channel.
  • Total unit continuous current rating of 10 A.
  • Galvanic isolation of 500 V DC between channels and the system bus to ensure signal integrity and protection.
  • Wide operating temperature range suitable for harsh industrial environments.

Technical Specifications

Product Model DSTD110A 57160001-TZ
Channels 32 Digital Outputs
Max Output Voltage 60 V DC per channel
Max Current per Channel 3 A
Total Unit Current 10 A continuous
Isolation 500 V DC channel-to-bus
Operating Temperature -25 degC to +70 degC
Storage Temperature -40 degC to +85 degC
Relative Humidity 5 - 95 % RH (non-condensing)

Installation Guidelines

  • Ensure the system power is completely disconnected before installing or removing the DSTD110A module.
  • Mount the unit in a clean, dry environment, ensuring adequate ventilation to maintain operating temperatures within the specified range.
  • Use shielded cables for signal wiring to minimize electromagnetic interference (EMI) in high-noise industrial environments.
  • Verify that all field wiring connections are secure and properly torqued to prevent intermittent signal loss.
  • Handle the module using proper electrostatic discharge (ESD) prevention techniques to avoid damage to internal components.

FAQ

What is the primary function of the DSTD110A?

The DSTD110A is a digital output connection unit used to interface field devices with the ABB Master control system, managing up to 32 digital output channels.

Can this module be used in extreme temperatures?

The module is rated for an operating temperature range of -25 degC to +70 degC, making it suitable for most standard industrial control room and cabinet environments.
