ABB DSTX120 57160001-MA Advant Master Connection Unit

ABB DSTX120 57160001-MA Advant Master Connection Unit

Description

The ABB DSTX120 (57160001-MA) is a connection unit designed for the Advant Master control system. This PC board-based module serves as a critical interface component, facilitating reliable signal routing and...

22 people are viewing this right now

Availability: Low stock: 3 left

SKU: DSTX120 57160001-MA
Vendor: ABB
Category: Connection Unit
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

Description

The ABB DSTX120 (57160001-MA) is a connection unit designed for the Advant Master control system. This PC board-based module serves as a critical interface component, facilitating reliable signal routing and connectivity within industrial automation architectures. It is engineered to maintain signal integrity in demanding environments while supporting the operational requirements of the Advant Master platform.

Features

  • Designed for integration with ABB Advant Master systems.
  • Supports 16 differential input signals for high-precision data acquisition.
  • Includes robust channel-to-bus isolation rated at 500 V dc.
  • Compact, board-level design optimized for standard control cabinet mounting.
  • Low power consumption profile suitable for high-density I/O configurations.

Technical Specifications

Product Model DSTX120 57160001-MA
Manufacturer ABB
Power Supply 24 V dc
Input Channels 16 differential
Max Voltage per Channel 30 V dc
Isolation 500 V dc channel-to-bus
Current Draw 50 mA @ 24 V dc
Operating Temperature 0 to +55 degC
Storage Temperature -40 to +85 degC
Relative Humidity 5 to 95% RH (non-condensing)

Installation Guidelines

  • Ensure the control system is powered down before installing or removing the connection unit to prevent electrical damage.
  • Handle the PCB with appropriate ESD (Electrostatic Discharge) precautions to protect sensitive components.
  • Verify that the 24 V dc power supply is stable and within the specified operating range before energizing the module.
  • Route signal cables away from high-voltage lines and sources of electromagnetic interference (EMI) to ensure signal accuracy.
  • Ensure adequate ventilation within the cabinet to maintain operating temperatures within the 0 to +55 degC range.

FAQ

What system is the DSTX120 compatible with?
The DSTX120 is specifically designed for use with the ABB Advant Master control system.

What is the primary function of this unit?
This is a connection unit (PC board) used to interface and route 16 differential input signals within the control system architecture.

Does this unit require external power?
Yes, the unit operates on a 24 V dc power supply with a current draw of approximately 50 mA.
