ABB SPDSI22 Digital Input Module

ABB SPDSI22 Digital Input Module

Product Description

The SPDSI22 is a 16-channel high-level digital input module designed for ABB Harmony / Symphony Plus (S+ Heritage) rack-based control systems. It provides a robust and electrically isolated interface between field-level status signals and...

18 people are viewing this right now

Availability: Low stock: 10 left

SKU: SPDSI22
Vendor: ABB
Category: Digital Input Module
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

Product Description

The SPDSI22 is a 16-channel high-level digital input module designed for ABB Harmony / Symphony Plus (S+ Heritage) rack-based control systems. It provides a robust and electrically isolated interface between field-level status signals and the system controller, ensuring reliable acquisition of discrete process information in demanding industrial environments.

A key advantage of the SPDSI22 is its universal input capability, allowing a single hardware platform to accept 24–125 VDC and 120 VAC signals. Integrated signal conditioning and hardware filtering suppress electrical noise and contact bounce, ensuring accurate, real-time status detection for control logic, interlocking, and sequence-of-events applications.

Technical Specifications

Parameter Specification
Model Number SPDSI22
Channel Count 16 Digital Input (DI) channels
Supported Input Voltages 24 VDC, 48 VDC, 125 VDC; 120 VAC
Input Isolation Galvanic isolation between field and system logic
Signal Conditioning Hardware debounce and EMI filtering
Status Indication Front-panel LEDs (module health & per-channel status)
Bus Interface INFI-Net / Harmony Control Bus
Form Factor Rack-mounted (INFI 90 / Symphony style)
Dimensions (L × W × H) 7.34 × 26.92 × 35.81 cm

Applications

The SPDSI22 is widely deployed in power generation and heavy industrial facilities, including:

  • Switchgear Status Monitoring – Breaker, isolator, and auxiliary contacts at 125 VDC

  • Emergency Shutdown (ESD) Systems – High-voltage interlocks and permissives

  • Control Room Interfaces – 120 VAC selector switches, pushbuttons, and alarms

  • Sequence-of-Events (SOE) – Accurate capture of discrete state changes

FAQ

Can different input voltages be used on different channels?
The module supports a wide voltage range, but channel grouping and configuration depend on field wiring and the associated termination unit. Mixed voltage operation is possible within defined installation rules.

Is the SPDSI22 compatible with legacy Bailey INFI 90 systems?
Yes. The SPDSI22 is designed for backward compatibility with INFI 90 rack architectures, enabling smooth migration to Harmony / Symphony Plus systems without major hardware changes.
