The AIP423 serves as a high-performance communication interface within Yokogawa CENTUM VP and CS 3000 DCS architectures. Acting as a critical node in the V-net communication network, it ensures deterministic, low-latency data exchange between Field...
Availability: Low stock: 99 left
Reliable Worldwide Delivery
30-Day Money-Back Guarantee
Need more details? Read our fullShipping PolicyandRefund Policy.
The AIP423 serves as a high-performance communication interface within Yokogawa CENTUM VP and CS 3000 DCS architectures. Acting as a critical node in the V-net communication network, it ensures deterministic, low-latency data exchange between Field Control Stations (FCS), Human Interface Stations (HIS), and other V-net components. It is engineered for mission-critical industrial environments, offering high reliability, redundancy support, and seamless system integration.
| Feature | Specification |
|---|---|
| Model | AIP423 (Style S1) |
| Data Rate | 10 Mbps (Deterministic) |
| Interface | V-net connector for coaxial or twinaxial cabling |
| Power Requirement | 24 V DC (from DCS backplane) |
| Network Topology | Bus or star (via couplers) |
| Redundancy | Fully compatible with dual-redundant V-net configurations |
| Operating Temperature | -10°C to +60°C (14°F to 140°F) |
| Construction | Industrial-grade shielding for EMI/RFI resistance |
| Unit Weight | 0.4 kg |
Deterministic Communication: Ensures timely delivery of control and status signals, avoiding collisions common in standard Ethernet.
High Availability: Supports redundant V-net architectures with "bumpless" switchover, maintaining communication even if a module or segment fails.
Hybrid Integration: Can interface legacy V-net segments with modern V-net IP networks via specialized bus converters.
Robust Industrial Design: EMI/RFI shielding and S1 hardware style optimize reliability and Mean Time Between Failures (MTBF).
Can the AIP423 be hot-swapped?
Yes. In a redundant configuration, the module can be replaced without shutting down the system if the partner module is active.
Maximum supported distance?
Standard V-net segment: 500 meters using coaxial cable; distances can be extended with repeaters or optical converters.
Compatibility with V-net IP?
The module is primarily for classic V-net (coaxial), but can bridge into hybrid V-net IP setups using bus converters.
