Allen-Bradley 1746-BLM Blow Molding Specialty Module

Allen-Bradley 1746-BLM Blow Molding Specialty Module

Description

The Allen-Bradley 1746-BLM is a high-performance, intelligent specialty module engineered for the plastics industry, specifically for use within the SLC 500 control system. It provides a tightly integrated solution for...

16 people are viewing this right now

Availability: In stock

SKU: 1746-BLM
Vendor: Allen-Bradley
Category: Specialty I/O Module
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

Description

The Allen-Bradley 1746-BLM is a high-performance, intelligent specialty module engineered for the plastics industry, specifically for use within the SLC 500 control system. It provides a tightly integrated solution for controlling blow molding machinery, including continuous extrusion, accumulator head, and reciprocating screw machines. The module functions as a co-processor, performing complex parison profile control and servo-loop tasks independently of the SLC 500 processor's scan time, ensuring high-speed, deterministic performance.

Features

  • Four independent axes of PID control, typically configured for parison and accumulator push-out applications.
  • High-speed loop update time of 100 microseconds for precise motion control.
  • 256 points of profile resolution with interpolation for smooth wall thickness transitions.
  • Dynamic profile adjustment capabilities, allowing for part weight changes without altering the established parison profile shape.
  • Integrated 14-bit resolution analog I/O and digital I/O for comprehensive machine interface.

Applications

This module is designed for demanding plastic processing environments, including:

  • Continuous extrusion blow molding machines.
  • Accumulator head blow molding systems.
  • Reciprocating screw blow molding machinery.
  • Applications requiring high-speed, synchronized parison profile control.

Technical Specifications

Brand Allen-Bradley
Product Line SLC 500
Module Type Blow Molding Specialty Module
Axes 4 Independent
Analog I/O 4 Inputs / 4 Outputs (14-bit)
Digital I/O 4 Inputs / 4 Outputs
Loop Update Time 100 µs
Backplane Current (5V DC) 110 mA
Backplane Current (24V DC) 85 mA
Isolation Voltage 500V DC
Operating Temperature 0 to 60 degC (32 to 140 degF)

Installation Guidelines

  • Ensure the SLC 500 rack is powered down before inserting or removing the 1746-BLM module to prevent electrical damage.
  • Install the module in an appropriate slot within the SLC 500 chassis, ensuring it is fully seated and the retaining screws are tightened.
  • Follow standard industrial grounding practices for the chassis and I/O wiring to minimize EMI.
  • Use shielded cables for analog signal connections to maintain signal integrity and prevent noise interference.
  • Maintain adequate ventilation within the control cabinet to ensure the module operates within its specified temperature range of 0 to 60 degC.

FAQ

What is the primary function of the 1746-BLM?

The 1746-BLM acts as a dedicated co-processor for the SLC 500 system, offloading complex parison profile control and servo-loop tasks from the main CPU to provide high-speed, independent control of blow molding machinery.

Can I adjust the part weight while the machine is running?

Yes, the module allows operators to dynamically adjust profile parameters, such as overall part weight, without the need to alter the established shape of the parison profile.
