Allen-Bradley 1746-OA16 SLC 500 16-Point AC Output Module

Allen-Bradley 1746-OA16 SLC 500 16-Point AC Output Module

Description

The Allen-Bradley 1746-OA16 is a 16-point AC output module designed for use with the SLC 500 programmable logic controller system. This module provides reliable, high-density output control for industrial applications...

20 people are viewing this right now

Availability: Low stock: 4 left

SKU: 1746-OA16
Vendor: Allen-Bradley
Category: PLC I/O Module
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

Description

The Allen-Bradley 1746-OA16 is a 16-point AC output module designed for use with the SLC 500 programmable logic controller system. This module provides reliable, high-density output control for industrial applications requiring 120/240V AC switching. It is engineered to interface directly with the SLC 500 backplane, facilitating seamless integration into existing control racks.

Features

  • 16 isolated AC output points for flexible control configurations.
  • Operating voltage range of 85-265V AC, suitable for standard industrial AC power environments.
  • Designed for high-density I/O requirements in SLC 500 chassis systems.
  • Robust construction for demanding industrial environments.
  • Backplane current load of 370 mA.

Applications

This module is typically utilized in manufacturing and process automation for driving AC-powered loads such as solenoid valves, motor starters, contactors, and indicating lamps. It is a standard component for SLC 500 rack-based automation systems.

Technical Specifications

Product Model 1746-OA16
Manufacturer Allen-Bradley
Number of Outputs 16
Voltage Range 85-265V AC
Backplane Current Load 370 mA
Weight 0.45 kg

Installation Guidelines

  • Ensure the SLC 500 system power is disconnected before installing or removing the module to prevent electrical shock or damage to the backplane.
  • Verify the module is fully seated in the chassis slot and secured with the top and bottom locking tabs.
  • Use appropriate wire gauges and ensure all terminal connections are tightened to the specified torque to prevent loose contacts.
  • Maintain proper spacing for ventilation to prevent overheating during operation.
  • Follow standard ESD (Electrostatic Discharge) precautions when handling the module to protect internal circuitry.

FAQ

What is the operating voltage of the 1746-OA16?

The module operates within a voltage range of 85-265V AC.

How many outputs does this module provide?

The 1746-OA16 provides 16 discrete AC output points.

Is this module compatible with all SLC 500 chassis?

Yes, it is designed to mount into any standard SLC 500 I/O chassis slot.
