Allen-Bradley 1746-SIM Input Simulator Module for SLC 500

Allen-Bradley 1746-SIM Input Simulator Module for SLC 500

Description

The Allen-Bradley 1746-SIM is a diagnostic and commissioning tool engineered for the SLC 500 platform. This input simulator module serves as a critical aid for engineers and technicians, enabling the...

29 people are viewing this right now

Availability: Low stock: 8 left

SKU: 1746-SIM
Vendor: Allen-Bradley
Category: PLC I/O Module
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

Description

The Allen-Bradley 1746-SIM is a diagnostic and commissioning tool engineered for the SLC 500 platform. This input simulator module serves as a critical aid for engineers and technicians, enabling the testing and verification of PLC ladder logic programs without requiring physical field devices such as sensors, limit switches, or pushbuttons. By utilizing 16 integrated toggle switches, the module allows for the manual triggering of input bits, facilitating efficient system development, debugging, and troubleshooting in a controlled environment.

Features

  • 16 independent toggle switches for manual input simulation.
  • Gold-plated contacts ensure high-reliability signal switching.
  • Compact design specifically for SLC 500 I/O chassis integration.
  • Supports rapid logic testing and system commissioning.
  • Compatible with 24V DC sinking and sourcing I/O modules.

Applications

This module is primarily used in industrial automation environments for:

  • Offline and online PLC program debugging.
  • Commissioning of new machine control sequences.
  • Verification of I/O mapping and ladder logic functionality.
  • Educational and training environments for PLC programming.

Technical Specifications

Brand Allen-Bradley
Product Line SLC 500
Device Type I/O Simulator
Number of Channels 16
Voltage Category 24V DC
Backplane Current (5V DC) 215 mA
Update Time 2 ms
Operating Temperature 0 to 60 degC (32 to 140 degF)
Storage Temperature -40 to 85 degC (-40 to 185 degF)
Relative Humidity 5% to 95% (non-condensing)

Installation Guidelines

  • Compatibility Warning: The 1746-SIM is designed for 24V DC sinking and sourcing modules (e.g., 1746-IB16, 1746-ITB16, 1746-IV16, 1746-ITV16, 1746-IN16). Do not install on high-voltage AC modules to prevent equipment damage or electrical hazard.
  • Handling: Ensure the PLC chassis power is off before inserting or removing the module to prevent electrical arcing or damage to the backplane connectors.
  • ESD Precautions: Always follow standard electrostatic discharge (ESD) prevention practices when handling the module.
  • Mounting: Ensure the module is fully seated in the SLC 500 chassis slot and secured properly.

FAQ

Can I use this module with AC input cards?

No. The 1746-SIM is strictly for use with 24V DC sinking and sourcing modules. Using it with AC modules will result in permanent damage to the simulator and potentially the PLC hardware.

Does this module require external power?

The 1746-SIM draws its power from the SLC 500 backplane (215 mA at 5V DC). No additional external power supply is required for the simulator itself.
