Allen-Bradley 1746SC-CTR4 Counter Flow Meter Input Module

Allen-Bradley 1746SC-CTR4 Counter Flow Meter Input Module

Description

The Allen-Bradley 1746SC-CTR4 is a specialized 4-channel counter and flow meter input module designed for the SLC 500 controller platform. This module is engineered to interface directly with turbine flow...

28 people are viewing this right now

Availability: Low stock: 8 left

SKU: 1746SC-CTR4
Vendor: Allen-Bradley
Category: Counter Input Module
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

Description

The Allen-Bradley 1746SC-CTR4 is a specialized 4-channel counter and flow meter input module designed for the SLC 500 controller platform. This module is engineered to interface directly with turbine flow meters and other pulse-generating sensors, providing high-speed counting capabilities essential for precise flow measurement and totalization in industrial control systems.

Features

  • 4-Channel input configuration for multi-point monitoring.
  • Supports high-speed pulse counting up to 50 kHz.
  • Optimized for turbine flow meter signal processing.
  • Input impedance of 25 kOhms for signal integrity.
  • Compact SLC 500 form factor for efficient rack space utilization.

Technical Specifications

Model 1746SC-CTR4
Channel Count 4
Maximum Frequency 50 kHz
Input Impedance 25 kOhms
Current Consumption 225 mA
Power Dissipation 1.75 W (max)
Weight 0.18 kg

Installation Guidelines

  • Ensure the SLC 500 chassis is powered down before inserting or removing the module to prevent electrical damage.
  • Verify that the module is fully seated in the backplane slot and secured with the provided mounting screws.
  • Use shielded twisted-pair cabling for flow meter inputs to minimize electromagnetic interference (EMI) in high-noise industrial environments.
  • Maintain proper grounding practices for the chassis to ensure signal stability and operator safety.
  • Avoid routing signal cables in parallel with high-voltage power lines.

FAQ

What is the primary application of the 1746SC-CTR4? This module is primarily used for high-speed pulse counting and flow rate measurement when integrated with turbine flow meters in an Allen-Bradley SLC 500 system.

Is this module compatible with standard SLC 500 racks? Yes, the 1746SC-CTR4 is designed to fit into standard Allen-Bradley 1746 I/O chassis.
