Allen-Bradley 1756-CNB/E ControlLogix ControlNet Communication Bridge Module

Allen-Bradley 1756-CNB/E ControlLogix ControlNet Communication Bridge Module

Description

The Allen-Bradley 1756-CNB/E is a ControlLogix ControlNet communication bridge module designed to facilitate high-speed data exchange between ControlLogix controllers and other devices on a ControlNet network. This module acts as...

15 people are viewing this right now

Availability: Low stock: 8 left

SKU: 1756-CNB/E
Vendor: Allen-Bradley
Category: Communication Bridge Module
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

Description

The Allen-Bradley 1756-CNB/E is a ControlLogix ControlNet communication bridge module designed to facilitate high-speed data exchange between ControlLogix controllers and other devices on a ControlNet network. This module acts as a bridge, allowing for efficient communication and control across distributed I/O, peer-to-peer messaging, and controller-to-controller data transfer.

Features

  • Supports up to 99 nodes on a single ControlNet network.
  • Provides up to 64 communication connections.
  • Standard ControlNet communication rate of 5 Mbps.
  • Designed for seamless integration within the ControlLogix chassis environment.
  • Optimized for deterministic, high-speed industrial communication.

Technical Specifications

Product Model 1756-CNB/E
Series ControlLogix
Module Type ControlNet Bridge Module
Communication Rate 5 Mbps
Max Nodes 99
Max Connections 64
Input Current (5.1V DC) 970 mA
Input Current (24V DC) 1.7 mA
Thermal Dissipation 17.4 BTU/hr

Installation Guidelines

  • Ensure the ControlLogix chassis is powered down before inserting or removing the module to prevent electrical damage.
  • Slide the module into the designated chassis slot and secure it using the top and bottom latches.
  • Ensure proper grounding of the ControlLogix chassis to a common ground point to minimize EMI interference.
  • Use shielded ControlNet cabling and appropriate tap connectors to maintain network integrity.
  • Verify that the module is firmly seated and the backplane connector is fully engaged.

FAQ

What is the primary function of the 1756-CNB/E?

The 1756-CNB/E serves as a communication bridge that allows ControlLogix controllers to communicate over the ControlNet network, supporting I/O control and messaging.

Can this module be hot-swapped?

Yes, the ControlLogix system supports Removal and Insertion Under Power (RIUP), allowing you to replace the module without powering down the entire chassis, provided the environment is not hazardous.

What is the communication speed of this module?

The module operates at a fixed ControlNet communication rate of 5 megabits per second.
