Allen-Bradley 1756-DMD30 ControlLogix 1-Axis Drive Control Module

Allen-Bradley 1756-DMD30 ControlLogix 1-Axis Drive Control Module

Description

The Allen-Bradley 1756-DMD30 is a specialized drive control module designed for the ControlLogix platform. This single-axis motion control module provides precise interface capabilities for drive systems, utilizing fiber optic communication...

23 people are viewing this right now

Availability: Low stock: 10 left

SKU: 1756-DMD30
Vendor: Allen-Bradley
Category: Motion Control Module
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

Description

The Allen-Bradley 1756-DMD30 is a specialized drive control module designed for the ControlLogix platform. This single-axis motion control module provides precise interface capabilities for drive systems, utilizing fiber optic communication to ensure high-speed, noise-immune data transfer within industrial automation environments. It is engineered to integrate seamlessly into a standard ControlLogix chassis, facilitating advanced motion control applications.

Features

  • Single-axis drive control functionality for high-precision motion tasks.
  • Fiber optic interface for reliable, interference-free communication.
  • Integrated LED status indicators for real-time diagnostic monitoring.
  • Designed for high-performance integration within the Allen-Bradley ControlLogix architecture.
  • Compact module design optimized for standard rack mounting.

Technical Specifications

Model 1756-DMD30
Control Axis 1-Axis
Power Requirements 1.35 Amps at 5.1 VDC
Operating Voltage 24 VDC
Peak Power Dissipation 6.96 Watts
Thermal Dissipation 23.7 BTU/hr
Operating Temperature 0 to 60 degC (32 to 140 degF)
Storage Temperature -40 to 85 degC (-40 to 185 degF)

Installation Guidelines

  • Ensure the ControlLogix chassis is powered down before inserting or removing the 1756-DMD30 module to prevent electrical damage.
  • Verify that the module is fully seated in the chassis slot and that the locking tabs are engaged.
  • Handle the module using proper ESD (Electrostatic Discharge) precautions to protect sensitive internal components.
  • Route fiber optic cables carefully, avoiding sharp bends or excessive tension that could compromise signal integrity.
  • Maintain adequate clearance around the module to allow for proper airflow and heat dissipation, adhering to the specified thermal dissipation limits.

FAQ

What is the primary function of the 1756-DMD30?

The 1756-DMD30 acts as a single-axis drive control interface for the ControlLogix system, allowing the PLC to command and monitor drive operations via fiber optic communication.

Is this module compatible with standard ControlLogix chassis?

Yes, the 1756-DMD30 is designed to be installed in a standard Allen-Bradley ControlLogix I/O chassis.

What are the power requirements for this module?

The module operates on 24 VDC and consumes 1.35 Amps at 5.1 VDC from the chassis backplane.
