Allen-Bradley 1756-IF4FXOF2F ControlLogix High-Speed Analog I/O Module

Allen-Bradley 1756-IF4FXOF2F ControlLogix High-Speed Analog I/O Module

Description

The Allen-Bradley 1756-IF4FXOF2F is a high-speed, combination analog input and output module designed for the ControlLogix platform. This module provides advanced signal processing capabilities for demanding industrial control applications, featuring...

21 people are viewing this right now

Availability: Low stock: 8 left

SKU: 1756-IF4FXOF2F
Vendor: Allen-Bradley
Category: Analog I/O Module
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

Description

The Allen-Bradley 1756-IF4FXOF2F is a high-speed, combination analog input and output module designed for the ControlLogix platform. This module provides advanced signal processing capabilities for demanding industrial control applications, featuring four high-speed differential inputs and two high-speed analog outputs. It is engineered to handle both voltage and current signals, offering precise conversion and fast response times required for high-performance automation tasks.

Features

  • Four high-speed, sub-millisecond differential analog inputs.
  • Two high-speed analog outputs capable of both current and voltage signaling.
  • Flexible signal range support including +/- 10V, 0-10V, 0-5V, and 0-20 mA.
  • High-resolution analog-to-digital and digital-to-analog conversion for accurate process control.
  • Integrated within the standard ControlLogix backplane for seamless system communication.

Technical Specifications

Module Type High-Speed Analog I/O
Inputs 4 Differential (High-Speed)
Outputs 2 (High-Speed)
Input Ranges +/- 10V, 0-10V, 0-5V, 0-20 mA
Output Ranges +/- 10V, 0-20 mA
Input Resolution 14-bit (Voltage), 12-bit (Current)
Output Resolution 13-bit (Current), 14-bit (Voltage)
Manufacturer Allen-Bradley

Installation Guidelines

  • Ensure the ControlLogix chassis is powered down before inserting or removing the 1756-IF4FXOF2F module to prevent electrical damage.
  • Verify that the module is properly seated in the chassis slot and that the locking tab is fully engaged.
  • Use shielded twisted-pair cabling for all analog signal connections to minimize electromagnetic interference (EMI).
  • Maintain proper grounding practices for the analog signal common to ensure measurement accuracy and signal integrity.
  • Avoid routing signal cables near high-voltage power lines or high-frequency switching equipment.

FAQ

What is the primary function of the 1756-IF4FXOF2F?
This module acts as a combination I/O interface for the ControlLogix system, allowing for the processing of high-speed analog inputs and the generation of analog outputs in a single module footprint.

Does this module support both current and voltage signals?
Yes, the module is software-configurable to support various ranges for both voltage and current inputs and outputs as specified in the technical parameters.
