Allen-Bradley 1756-IF8I ControlLogix Isolated Analog Input Module

Allen-Bradley 1756-IF8I ControlLogix Isolated Analog Input Module

The Allen-Bradley 1756-IF8I is a high-performance analog input module designed for the ControlLogix platform. This module provides eight isolated input channels, allowing for flexible configuration across various industrial measurement applications....

17 people are viewing this right now

Availability: Low stock: 4 left

SKU: 1756-IF8I
Vendor: Allen-Bradley
Category: Analog Input Module
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

The Allen-Bradley 1756-IF8I is a high-performance analog input module designed for the ControlLogix platform. This module provides eight isolated input channels, allowing for flexible configuration across various industrial measurement applications. It supports both voltage and current signals, making it a versatile solution for process control and monitoring tasks requiring galvanic isolation between channels.

Features

  • Eight isolated analog input channels.
  • Supports configurable signal ranges including -10 to 10V, 0 to 10V, 0 to 5V, and 0 to 20mA.
  • Sigma-Delta conversion method for high-resolution data acquisition.
  • 16-bit to 21-bit resolution depending on configuration.
  • Compatible with the standard ControlLogix backplane architecture.

Applications

This module is engineered for use in demanding industrial environments where signal isolation is critical to prevent ground loops and noise interference. It is frequently utilized in process automation, chemical processing, power generation, and manufacturing systems that require precise monitoring of analog sensors and transmitters.

Technical Specifications

Model 1756-IF8I
Manufacturer Allen-Bradley
Series ControlLogix
Input Channels 8 (Isolated)
Signal Ranges -10 to 10V, 0 to 10V, 0 to 5V, 0 to 20mA
Conversion Method Sigma-Delta
Resolution 16-21 bits
Backplane Current (5.1V) 200 mA
Backplane Current (24V) 150 mA or 400 mA
Enclosure Type Open

Installation Guidelines

  • Ensure the ControlLogix chassis is powered down before inserting or removing the module to prevent electrical damage.
  • Properly seat the module into the designated slot on the backplane and secure it using the integrated latching mechanism.
  • Use shielded twisted-pair cabling for all analog inputs to minimize EMI and ensure signal integrity.
  • Verify that all field wiring is terminated correctly at the Removable Terminal Block (RTB) before applying power.
  • Maintain adequate ventilation around the chassis to ensure optimal operating temperatures.

FAQ

Is the 1756-IF8I module isolated? Yes, this module features 8 isolated channels, providing electrical separation between inputs to improve system reliability and noise immunity.

What is the resolution of this module? The 1756-IF8I provides a resolution ranging from 16 to 21 bits, depending on the specific input range and filter settings selected.
