Allen-Bradley 1756-IH16ISOE ControlLogix Digital Isolated Input Module

Allen-Bradley 1756-IH16ISOE ControlLogix Digital Isolated Input Module

Description

The Allen-Bradley 1756-IH16ISOE is a high-performance Digital Isolated Input Module designed for the ControlLogix platform. This module features 16 individually isolated inputs with Sequence of Events (SOE) recording capabilities, making...

20 people are viewing this right now

Availability: Low stock: 8 left

SKU: 1756-IH16ISOE
Vendor: Allen-Bradley
Category: Digital Input Module
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

Description

The Allen-Bradley 1756-IH16ISOE is a high-performance Digital Isolated Input Module designed for the ControlLogix platform. This module features 16 individually isolated inputs with Sequence of Events (SOE) recording capabilities, making it ideal for applications requiring precise time-stamping of critical system changes. It is engineered to handle 125V DC sink/source signals within a robust operating range of 90-140V DC, ensuring reliable integration into complex industrial control environments.

Features

  • 16 individually isolated input channels for enhanced signal protection.
  • Integrated Sequence of Events (SOE) functionality for high-resolution event logging.
  • Compatible with 125V DC nominal input voltages.
  • Designed for high-density I/O requirements within the ControlLogix chassis.
  • Low power dissipation of 5.5 Watts at 60 degC.

Technical Specifications

Module Type Digital Isolated Input (SOE)
Input Voltage 125V DC (Sink/Source)
Operating Range 90-140V DC
Backplane Current (5V) 275 mA
Backplane Current (24V) 2 mA
Input Delay Time 75 microseconds + filter time
Min Operating Current 1.15 mA at 90V DC
Max Operating Current 1.85 mA at 140V DC
Max Off-State Current 0.3 mA

Installation Guidelines

  • Ensure the ControlLogix chassis is powered down before inserting or removing the module.
  • Use appropriate shielded cabling to minimize EMI interference in high-voltage DC environments.
  • Verify that the module is fully seated in the chassis slot and secured with the top and bottom latches.
  • Adhere to standard ESD protection practices when handling the module to prevent damage to internal circuitry.
  • Proper grounding of the chassis backplane is essential for maintaining signal integrity and safety.

FAQ

What is the primary function of the SOE feature on this module?
The Sequence of Events (SOE) capability allows the module to record the precise timing of input state changes, which is critical for fault analysis and process monitoring in time-sensitive applications.

Can this module be used in a standard ControlLogix chassis?
Yes, the 1756-IH16ISOE is designed to fit standard 1756 ControlLogix chassis and requires a compatible Removable Terminal Block (RTB) for field wiring.
