Allen-Bradley 1756-IM16I ControlLogix 16-Point Isolated Digital Input Module

Allen-Bradley 1756-IM16I ControlLogix 16-Point Isolated Digital Input Module

Description

The Allen-Bradley 1756-IM16I is a high-performance digital input module designed for the ControlLogix platform. This module features 16 individually isolated inputs, providing reliable signal processing for 240V AC industrial applications....

27 people are viewing this right now

Availability: In stock

SKU: 1756-IM16I
Vendor: Allen-Bradley
Category: Digital Input Module
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

Description

The Allen-Bradley 1756-IM16I is a high-performance digital input module designed for the ControlLogix platform. This module features 16 individually isolated inputs, providing reliable signal processing for 240V AC industrial applications. It is engineered to maintain signal integrity in demanding control environments by offering robust electrical isolation between input channels.

Features

  • 16 individually isolated digital input channels.
  • Designed for 240V AC input voltage applications.
  • Programmable input delay times of 9 or 18 milliseconds to filter noise and bounce.
  • Seamless integration with the Allen-Bradley ControlLogix backplane.
  • Wide operating voltage range from 159V AC to 265V AC.

Technical Specifications

Model 1756-IM16I
Module Type Isolated Digital Input
Input Voltage 240V AC
Voltage Range 159-265V AC
Input Points 16 (Isolated)
Min. Operating Current 5 mA at 159V AC, 60 Hz
Max. Operating Current 13 mA at 265V AC, 60 Hz
Off-State Current 2.5 mA (max)
Programmable Delay 9 or 18 ms

Installation Guidelines

  • Ensure the ControlLogix chassis is powered down before inserting or removing the module to prevent electrical damage.
  • Verify that the module is fully seated in the chassis slot and that the locking tab is engaged.
  • Use shielded cabling for input signals to minimize electromagnetic interference (EMI) in high-voltage environments.
  • Adhere to proper grounding practices for the ControlLogix chassis to maintain system-wide electrical safety.
  • Ensure proper ventilation around the chassis to maintain operating temperatures within the manufacturer's specified limits.

FAQ

What is the primary function of the 1756-IM16I?

This module is used to interface 240V AC field signals with the ControlLogix controller, providing electrical isolation for each of the 16 input points.

Can the input delay be adjusted?

Yes, the module supports programmable input delay settings of either 9 or 18 milliseconds, allowing for flexible configuration based on your specific application requirements.

Is this module compatible with standard ControlLogix chassis?

Yes, the 1756-IM16I is designed specifically for the Allen-Bradley ControlLogix I/O chassis series.
