Allen-Bradley 1756-M14 ControlLogix Expansion Memory Module

Allen-Bradley 1756-M14 ControlLogix Expansion Memory Module

Description

The Allen-Bradley 1756-M14 is a specialized internal expansion memory module designed for the ControlLogix automation platform. By utilizing high-speed Dynamic Random Access Memory (DRAM), this module provides the necessary volatile...

25 people are viewing this right now

Availability: Low stock: 4 left

SKU: 1756-M14
Vendor: Allen-Bradley
Category: PLC Memory Module
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

Description

The Allen-Bradley 1756-M14 is a specialized internal expansion memory module designed for the ControlLogix automation platform. By utilizing high-speed Dynamic Random Access Memory (DRAM), this module provides the necessary volatile memory extension to support larger control programs, complex instruction sets, and expanded data arrays. It is engineered for seamless integration into standard ControlLogix chassis architectures, allowing for system scalability without the need for a full processor replacement.

Features

  • High-density DRAM architecture for low-latency data access.
  • Compact, single-slot design for efficient chassis utilization.
  • Ultra-low power consumption, minimizing thermal output within the enclosure.
  • Robust electrical noise filtering and surge protection.
  • Designed for high-vibration and high-shock industrial environments.

Applications

This module is ideal for industrial environments requiring increased memory capacity for distributed control networks, high-speed assembly line automation, and complex process loops where standard processor memory limits may be reached.

Technical Specifications

Model 1756-M14
Memory Type DRAM
Backplane Current (5 VDC) 0.03 A
Backplane Current (24 VDC) 0 A
Power Dissipation 0.15 W
Isolation Voltage 30 V continuous
Surge Immunity 2 kV line-to-line
ESD Immunity 6 kV contact
Operating Vibration 2 g at 10 to 500 Hz
Operating Shock 30 g
Non-Operating Shock 50 g
Humidity 5% to 95% non-condensing

Installation Guidelines

  • Ensure the ControlLogix chassis power is disconnected before installing or removing the module.
  • Handle the module by the edges to prevent electrostatic discharge (ESD) damage to sensitive components.
  • Align the module carefully with the chassis guide rails and ensure it is fully seated in the backplane connector.
  • Secure the module using the top and bottom latching mechanisms to ensure proper grounding and vibration resistance.
  • Verify that the module is not installed in an environment exceeding the specified temperature or humidity ranges.

FAQ

Does this module require external power? No, the 1756-M14 draws all required power directly from the ControlLogix chassis backplane.

Is this module compatible with all ControlLogix processors? The 1756-M14 is designed for the ControlLogix platform; please verify your specific processor firmware and hardware revision compatibility in the official Allen-Bradley technical documentation.
