Allen-Bradley 1756SC-IF8H ControlLogix Analog Current/Voltage Input Module

Allen-Bradley 1756SC-IF8H ControlLogix Analog Current/Voltage Input Module

Description

The Allen-Bradley 1756SC-IF8H is a specialized 8-point analog input module designed for the ControlLogix platform. This module provides high-precision signal processing for both current and voltage inputs and includes integrated...

22 people are viewing this right now

Availability: Low stock: 4 left

SKU: 1756SC-IF8H
Vendor: Allen-Bradley
Category: Analog Input Module
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

Description

The Allen-Bradley 1756SC-IF8H is a specialized 8-point analog input module designed for the ControlLogix platform. This module provides high-precision signal processing for both current and voltage inputs and includes integrated HART (Highway Addressable Remote Transducer) support, allowing for seamless communication with smart field devices. As a component of the ControlLogix system, it is engineered to provide reliable data acquisition in demanding industrial automation environments.

Features

  • 8-point analog input capacity for versatile signal monitoring.
  • Integrated HART protocol support for advanced device diagnostics and configuration.
  • Compatible with standard ControlLogix chassis and backplane communication.
  • Designed for high-accuracy current and voltage measurement in process control applications.
  • Robust industrial construction suitable for harsh operating conditions.

Applications

This module is typically deployed in process industries requiring precise analog monitoring and HART device integration, such as chemical processing, oil and gas, water treatment, and power generation. It is commonly used to interface with transmitters, flow meters, and pressure sensors that utilize HART communication for remote diagnostics.

Technical Specifications

Model 1756SC-IF8H
Manufacturer Allen-Bradley
Module Type Analog Input Module
Input Points 8
Communication HART Enabled
System Compatibility ControlLogix
Weight 0.24 kg

Installation Guidelines

  • Ensure the ControlLogix chassis is powered down before inserting or removing the module to prevent electrical damage.
  • Verify that the module is fully seated in the chassis slot and the locking mechanism is engaged.
  • Use shielded twisted-pair cabling for analog signals to minimize electromagnetic interference (EMI).
  • Ensure proper grounding of the cable shields at the signal source or the cabinet ground bus, following standard industrial grounding practices.
  • Maintain adequate clearance around the module to ensure proper airflow and cooling within the control cabinet.

FAQ

Is the 1756SC-IF8H still in production?
No, this module has been discontinued by the manufacturer. We offer refurbished or surplus units to support legacy system maintenance.

Does this module support HART communication?
Yes, the 1756SC-IF8H is specifically designed with HART protection and communication capabilities for smart field instrumentation.
