Allen-Bradley 1769-HSC CompactLogix High-Speed Counter Module

Allen-Bradley 1769-HSC CompactLogix High-Speed Counter Module

Product Overview

The 1769-HSC is a high-speed counter module for CompactLogix systems, designed for encoder, pulse, and rate measurement applications. It supports high-speed quadrature and pulse counting with fast local...

15 people are viewing this right now

Availability: Low stock: 99 left

SKU: 1769-HSC
Vendor: Allen Bradley
Category: Counter Module
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

Product Overview

The 1769-HSC is a high-speed counter module for CompactLogix systems, designed for encoder, pulse, and rate measurement applications. It supports high-speed quadrature and pulse counting with fast local processing for accurate position and motion control.

Technical Specifications

Parameter Specification
Part Number 1769-HSC
Number of Counters 2 Quadrature or 4 Pulse/Direction
Input Voltage 5V DC or 24V DC
Maximum Frequency 1 MHz (Counter), 250 kHz (Quadrature)
Onboard Outputs 4 Fast 24V DC Outputs
Input Impedance 250 Ω (5V), 2.5 kΩ (24V)
Backplane Current Draw 425 mA at 5.1V
Isolation 30V Continuous
Weight 0.20 kg

Engineering Advantages

  • High-speed local signal processing

  • Supports encoder and pulse applications

  • Fast onboard output response

  • Flexible voltage and counting modes

  • Easy integration with Studio 5000

FAQs

Can the module accept 5V encoder signals?
Yes. The 1769-HSC supports both 5V DC and 24V DC input devices.

What are the onboard outputs used for?
They provide ultra-fast response for target count triggering without PLC scan delays.

Does the module support quadrature encoders?
Yes. It supports two quadrature encoder channels.

Is this product 100% Brand New?
Yes. This 1769-HSC module is supplied in 100% Brand New condition with a 2-year warranty.
