Allen-Bradley 2711P-K15C15D1 PanelView Plus 1500 Operator Terminal

Allen-Bradley 2711P-K15C15D1 PanelView Plus 1500 Operator Terminal

The Allen-Bradley 2711P-K15C15D1 is a high-performance industrial operator interface terminal from the PanelView Plus 1500 series. Engineered for demanding environments such as power generation, heavy manufacturing, and water treatment, this...

22 people are viewing this right now

Availability: Low stock: 2 left

SKU: 2711P-K15C15D1
Vendor: Allen-Bradley
Category: Operator Interface Terminal
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

The Allen-Bradley 2711P-K15C15D1 is a high-performance industrial operator interface terminal from the PanelView Plus 1500 series. Engineered for demanding environments such as power generation, heavy manufacturing, and water treatment, this terminal provides reliable real-time process monitoring and control. It features a 15-inch active-matrix TFT color display with a resolution of 1024 x 768, ensuring clear visualization of complex machine analytics and system status.

Features

  • Rugged Input Interface: Equipped with a durable stainless-steel dome membrane keypad designed for consistent tactile feedback and long-term reliability in high-vibration control rooms.
  • Display Technology: High-visibility 15-inch TFT display with a brightness of 300 cd/m2, optimized for readability in varied ambient lighting conditions.
  • Memory Architecture: Includes 64 MB of system RAM and 64 MB of non-volatile flash memory for stable application execution, alarm logging, and data retention.
  • Vibration Resistance: Chassis construction rated for continuous operation under mechanical stress up to 2G at frequencies between 57 Hz and 500 Hz.
  • Backlight System: Features a field-replaceable CCFL backlight assembly with an expected service life of 50,000 hours.

Technical Specifications

Model 2711P-K15C15D1
Display Size 15 inches
Display Type Color Active Matrix TFT
Resolution 1024 x 768 (18-bit)
Input Voltage 18 to 32 VDC (24 VDC nominal)
Operating Temperature 0 to 55 deg C
Storage Temperature -25 to 70 deg C
System RAM 64 MB
Flash Memory 64 MB

Installation Guidelines

  • Mounting: Ensure the unit is mounted in a panel with adequate clearance for ventilation to prevent overheating. Use the provided mounting clips to secure the bezel against the enclosure gasket for an IP-rated seal.
  • Power Wiring: Connect to a 24 VDC power source within the 18-32 VDC range. Ensure proper grounding of the chassis to a common earth ground point to mitigate EMI.
  • ESD Precautions: Always handle the unit with static-safe practices. Avoid touching internal components or exposed connector pins.
  • Maintenance: Power down the terminal before performing any maintenance, including the replacement of the CCFL backlight or cleaning of the membrane keypad.

FAQ

Q: What is the primary input method for this terminal?
A: This model utilizes a stainless-steel dome membrane keypad, which provides tactile feedback suitable for industrial environments.

Q: Can the backlight be replaced in the field?
A: Yes, the unit is designed with a field-replaceable CCFL backlight assembly to extend the operational life of the display.

Q: Is this terminal suitable for high-vibration applications?
A: Yes, the 2711P-K15C15D1 is rated to withstand continuous vibration up to 2G at frequencies between 57 Hz and 500 Hz.
