Allen-Bradley 1762-IF4 MicroLogix 4-Point Analog Input Module

Allen-Bradley 1762-IF4 MicroLogix 4-Point Analog Input Module

Description

The Allen-Bradley 1762-IF4 is a high-performance analog input expansion module designed for use with the MicroLogix 1200 and 1400 programmable logic controller systems. This module provides four differential, bipolar analog...

28 people are viewing this right now

Availability: Low stock: 4 left

SKU: 1762-IF4
Vendor: Allen-Bradley
Category: Analog Input Module
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

Description

The Allen-Bradley 1762-IF4 is a high-performance analog input expansion module designed for use with the MicroLogix 1200 and 1400 programmable logic controller systems. This module provides four differential, bipolar analog input channels, allowing for precise monitoring of voltage and current signals in industrial automation environments. It is engineered to integrate seamlessly into the MicroLogix I/O bus, providing reliable data acquisition for process control applications.

Features

  • Four differential, bipolar analog input channels.
  • Supports both voltage (-10.5 to +10.5V DC) and current (4 to 20 mA) signal ranges.
  • High-resolution 15-bit data conversion for accurate signal processing.
  • Repeatability of ±0.12% for consistent measurement performance.
  • Compact design optimized for MicroLogix expansion racks.

Technical Specifications

Product Model 1762-IF4
Product Family MicroLogix
Number of Inputs 4 Differential (Bipolar)
Voltage Range -10.5 to +10.5V DC
Current Range 4 to 20 mA (Full range -21 to +21 mA)
Resolution 15 bit
Repeatability ±0.12%
Weight 0.2 kg

Installation Guidelines

  • Ensure the controller power is disconnected before installing or removing the module from the I/O bus.
  • Mount the module in a clean, dry environment with adequate ventilation to prevent overheating.
  • Use shielded twisted-pair cabling for analog signal connections to minimize electromagnetic interference (EMI).
  • Ensure proper grounding of the cable shields at the signal source or the module common, depending on system design requirements.
  • Verify that all terminal connections are secure and that the module is firmly seated in the expansion slot.

FAQ

What is the primary function of the 1762-IF4?

The 1762-IF4 is an analog input module that converts external voltage or current signals into digital values that the MicroLogix PLC can process for control and monitoring tasks.

Is this module compatible with all MicroLogix controllers?

The 1762-IF4 is specifically designed for the MicroLogix 1200 and 1400 series. Please verify your specific controller model's compatibility with 1762-series expansion I/O before installation.

Can this module handle both voltage and current inputs?

Yes, the module supports both voltage (-10.5 to +10.5V DC) and current (4 to 20 mA) signals, which can be configured per channel via the PLC software.
