Allen-Bradley 1762-L40BWA MicroLogix 1200 40-Point Controller

Allen-Bradley 1762-L40BWA MicroLogix 1200 40-Point Controller

The Allen-Bradley 1762-L40BWA is a high-performance MicroLogix 1200 programmable logic controller designed for small to mid-sized industrial automation applications. This 40-point controller features an integrated 100-240V AC power supply, 24...

25 people are viewing this right now

Availability: Low stock: 1 left

SKU: 1762-L40BWA
Vendor: Allen-Bradley
Category: PLC Controller
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

The Allen-Bradley 1762-L40BWA is a high-performance MicroLogix 1200 programmable logic controller designed for small to mid-sized industrial automation applications. This 40-point controller features an integrated 100-240V AC power supply, 24 digital inputs, and 16 relay outputs, providing a flexible and robust solution for machine control and process automation.

Features

  • MicroLogix 1200 architecture with 40 integrated I/O points.
  • 24V DC digital inputs, including 4 high-speed inputs for precise counting and timing applications.
  • 16 relay outputs suitable for switching a wide range of AC and DC loads.
  • Integrated RS-232 communication port supporting DF1, DH-485, Modbus, and ASCII protocols.
  • Supports up to 6 additional 1762 expansion I/O modules for system scalability.
  • Flexible mounting options via DIN rail or panel mounting.

Applications

  • Industrial machinery and manufacturing automation.
  • Material handling systems, including conveyors and sorting equipment.
  • Process control for sensors, solenoids, and motor starters.
  • Packaging and food/beverage processing lines.
  • Building automation and localized control systems.

Technical Specifications

Model 1762-L40BWA
Power Supply 100-240V AC
Total I/O 40 Points (24 In / 16 Out)
Input Type 24V DC Sinking/Sourcing
Output Type Relay
Power Usage 82 VA
Heat Dissipation 22.0 W
Operating Temperature 0 degC to 55 degC
Communication RS-232 (8-pin Mini DIN)

Installation Guidelines

  • Mounting: Mount the unit horizontally. Maintain at least 50 mm (2 inches) of clearance on all sides for adequate ventilation, except for the right side where expansion modules are connected.
  • Debris Protection: Keep the protective debris strip on top of the unit during installation to prevent foreign objects from entering the circuitry. Remove only after wiring is complete.
  • Wiring: Ensure all wiring complies with local electrical codes. Disconnect all power before installing or removing expansion modules to prevent electrical damage.
  • Grounding: Proper chassis grounding is essential for electromagnetic compatibility and operational safety.
  • Environment: Install in an enclosure rated for the operating environment. Use climate control (fans or heaters) to maintain the specified operating temperature range.

FAQ

What is the 1762-L40BWA?

It is a 40-point Allen-Bradley MicroLogix 1200 controller with a 100-240V AC power supply, 24-point 24V DC inputs (including 4 fast inputs), and 16 relay outputs.

What are the expansion options?

The 1762-L40BWA supports up to 6 expansion modules, including analog, high-speed counter, and additional digital I/O modules.

What is the maximum load output of the 1762-L40BWA relay?

The relay outputs are rated for 25-125V DC or 120-240V AC, with a maximum control load capacity of 1440 VA.
