Allen-Bradley 1762-OB8 MicroLogix 8-Point Digital DC Output Module

Allen-Bradley 1762-OB8 MicroLogix 8-Point Digital DC Output Module

Description

The Allen-Bradley 1762-OB8 is a solid-state digital output expansion module designed for use with MicroLogix 1200 and 1500 programmable controller systems. This module provides eight points of 24V DC output,...

24 people are viewing this right now

Availability: Low stock: 10 left

SKU: 1762-OB8
Vendor: Allen-Bradley
Category: Digital Output Module
Related Series:

Shipping & Returns

Reliable Worldwide Delivery

  • Carriers: Shipped via DHL, FedEx, UPS, or USPS.
  • Dispatch: Orders processed in 1-2 business days and dispatched within 3-5 business days.
  • Tracking: Full tracking details provided via email upon shipment.

30-Day Money-Back Guarantee

  • Guarantee: 30-day return window for in-stock, factory-sealed products.
  • Condition: Items must be unopened, unused, and in original packaging.
  • Authenticity: We guarantee 100% original and authentic hardware.

Need more details? Read our fullShipping PolicyandRefund Policy.

Authenticity & Warranty

  • Genuine Guarantee: We supply only 100% original, brand-new, and factory-sealed industrial automation parts.
  • Full Coverage: Every component is backed by a 12-month comprehensive warranty from the date of purchase.
  • Traceability: All products come with original factory documentation and accessories for full industrial compliance.

Technical Support & Sourcing

  • Expert Assistance: Our technical team provides free consultation to help you verify compatibility for DCS and PLC systems.
  • Rare Part Sourcing: Specializing in obsolete and hard-to-find components from Allen-Bradley, Siemens, ABB, HIMA, and more.
  • Bulk Inquiries: Contact us at pambo@5gplc.com for volume pricing or customized project quotes.
View full product details

Description

The Allen-Bradley 1762-OB8 is a solid-state digital output expansion module designed for use with MicroLogix 1200 and 1500 programmable controller systems. This module provides eight points of 24V DC output, facilitating reliable control of field devices such as solenoids, contactors, and indicators within industrial automation environments.

Features

  • Provides 8 independent solid-state DC output channels.
  • Designed for seamless integration with MicroLogix 1200 and 1500 series controllers.
  • Operates within a 24V DC voltage category.
  • Compact hardware design suitable for space-constrained control cabinets.
  • Supports standard DIN rail mounting for quick installation and removal.

Technical Specifications

Model Number 1762-OB8
Product Type Digital DC Output Module
Number of Outputs 8
Operating Voltage Range 20.4 - 26.4V DC
Backplane Current 115 mA at 5V DC
Mounting Type DIN Rail
Series Compatibility MicroLogix 1200 / 1500

Installation Guidelines

  • Ensure the controller power is disconnected before installing or removing the module to prevent electrical damage.
  • Mount the module on a standard 35mm DIN rail, ensuring it is securely locked into the backplane connector.
  • Maintain adequate clearance around the module to allow for proper airflow and heat dissipation.
  • Use shielded cabling for output signals to minimize electromagnetic interference (EMI) in high-noise industrial environments.
  • Verify that the external power supply connected to the output terminals matches the 24V DC specification.

FAQ

What is the primary function of the 1762-OB8?

The 1762-OB8 is an expansion I/O module that adds eight digital DC output points to a MicroLogix 1200 or 1500 PLC system, allowing the controller to drive external DC-powered loads.

Is this module compatible with all MicroLogix controllers?

The 1762-OB8 is specifically designed for the MicroLogix 1200 and 1500 expansion I/O bus. It is not compatible with MicroLogix 1000 or 1100 series controllers.

What is the required power supply for the outputs?

The module operates within a voltage range of 20.4 to 26.4V DC. Ensure your field power supply is regulated and falls within this range for optimal performance.
